Description
The ABB SD802F (3BDH000012-REF) is a high-efficiency switch-mode power supply for Freelance AC 700F and AC 800F controllers. It converts AC or DC input into a stable 24V DC output to reliably power controllers, I/O modules, and field devices. Designed for industrial automation, it offers robust power reserves and protection for continuous operation in distributed control systems.
Specifications
-
Manufacturer: ABB
-
Model Designation: SD802F
-
Part Number: 3BDH000012-REF
-
Product Type: Switch-Mode Power Supply
-
Input Voltage: 100–240V AC / 110–250V DC
-
Output Voltage: 24V DC (Adjustable)
-
Output Current: 5A
-
Power Rating: 120W
-
Mounting: 35mm DIN Rail
-
Efficiency: Typically >88%
-
Operating Temperature: -25 to +70°C
Features
-
Wide Range Input: Accommodates various global power standards, reducing the need for regional inventory variants.
-
Redundancy Ready: Can be utilized in parallel configurations with external redundancy modules to increase system fault tolerance.
-
Overload Protection: Equipped with electronic short-circuit and overvoltage protection to safeguard downstream control hardware.
-
Convection Cooling: Designed for fanless operation, reducing mechanical failure points and extending the unit's operational lifespan.
-
Status Monitoring: Features integrated LED diagnostics for "DC OK" signaling, allowing for immediate visual verification of power health.
-
Compact Footprint: High power density design saves valuable rail space within standard industrial enclosures.
