Product Details
Description
The ICS Triplex T7310 is a high-integrity I/O Transceiver module designed for the Planet safety system architecture. It serves as the primary communication bridge between the main processor and the I/O modules, managing the distribution and synchronization of triplicated data across the system backplane to ensure fault-tolerant operation.
Specifications
-
Manufacturer: Rockwell Automation (ICS Triplex).
-
Country of Origin: United Kingdom.
-
Model Number: T7310.
-
Communication Bus: Triple Redundant Inter-Module Bus.
-
Input Voltage: 24 VDC nominal.
-
Power Dissipation: 12 Watts maximum.
-
Physical Weight: Approximately 1.2 kg (2.6 lbs).
-
Dimensions: 10.5" x 1.2" x 7.8" (266 mm x 31 mm x 198 mm).
-
Isolation Rating: 500 VDC logic to field.
-
Operating Temperature: -5°C to +60°C (23°F to 140°F).
-
Safety Rating: TÜV approved for SIL3 safety applications.
Features
-
Triplicated Signal Management: Orchestrates the flow of data across three independent channels to maintain the integrity of the 2oo3 (two-out-of-three) voting logic.
-
High-Speed Data Synchronization: Ensures that all I/O modules are perfectly synchronized with the main processor's scan cycle for deterministic control.
-
Fault Isolation Guarding: Prevents a single fault on the I/O bus from propagating to the main processor, protecting the core safety functions of the system.
-
Online Hot-Swap Support: Enables the removal and replacement of the transceiver module without interrupting the live process or compromising safety.
-
Continuous Self-Monitoring: Performs background health checks on the transceiver circuitry and the backplane interface to identify hardware failures instantly.
-
Diagnostic Status Display: Includes front-panel LED indicators that provide real-time visibility into bus activity, module health, and fault conditions.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
