Product Details
Overview:
The Honeywell TC-IDJ161 is a highly reliable 16-channel digital input module, designed to provide optical isolation for 24 VDC inputs in industrial automation systems. Ideal for integration with Honeywell Experion C200/C300 platforms, this module ensures accurate and noise-resistant data acquisition in demanding environments. The TC-IDJ161 delivers robust performance with built-in diagnostic LEDs and a compact design, making it a versatile and maintenance-friendly solution for control system applications.
Key Specifications:
-
Manufacturer: Honeywell
-
Model Number: TC-IDJ161
-
Channels: 16 discrete digital inputs
-
Input Voltage Range: 10–30 VDC
-
Input Current: Approx. 10 mA per channel
-
Isolation: Optically isolated inputs for noise immunity
-
Power Consumption:
-
100 mA @ 5.1 VDC
-
3 mA @ 24 VDC
-
Operating Temperature: -40°C to +70°C
-
Humidity Range: 5% to 95% RH, non-condensing
-
Dimensions: 24 × 16 × 8 cm
-
Mounting Type: Panel or rack-mounted
-
System Compatibility: Honeywell Experion C200/C300 platforms
Features:
-
Optical Isolation: Protects against electrical interference, ensuring high signal integrity and noise immunity.
-
Compact and Efficient: Space-saving design perfect for dense control layouts.
-
Diagnostic LEDs: Offers real-time input status and fault detection, enabling easy monitoring and troubleshooting.
-
Environmental Resilience: Reliable operation in extreme conditions, from -40°C to +70°C.
-
Plug-and-Play Integration: Seamlessly integrates into Honeywell control architectures, reducing installation time.
-
Versatile Input Handling: Supports a wide variety of logic levels and signal types.
-
Maintenance-Friendly: Hot-swappable for minimal downtime and efficient system operation.
-
Factory-Certified: Built to Honeywell’s rigorous reliability standards, ensuring long-term durability.
Applications:
The Honeywell TC-IDJ161 is ideal for applications in industrial automation systems, control systems, and process control environments requiring reliable digital signal acquisition. The module's optical isolation and high signal integrity make it a preferred choice for environments with electrical interference, ensuring safe and accurate data collection.
Frequently Asked Questions (FAQ):
Q: What is the input voltage range for the TC-IDJ161?
A: The TC-IDJ161 supports an input voltage range of 10–30 VDC, making it compatible with a wide range of industrial systems.
Q: How does the TC-IDJ161 protect against electrical noise?
A: The module is optically isolated, which ensures immunity to electrical noise and interference, providing high signal integrity even in noisy environments.
Q: Can the TC-IDJ161 be used in extreme temperatures?
A: Yes, the TC-IDJ161 is designed to operate reliably in extreme temperatures ranging from -40°C to +70°C, making it suitable for harsh industrial conditions.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
