Product Details
Overview
The 2711P-T12W22D8S is a 12.1-inch touchscreen Human Machine Interface (HMI) from Allen-Bradley’s PanelView Plus 7 Standard family. It provides an intuitive interface for machine and process control, featuring a high-resolution widescreen display and durable design for industrial environments. With flexible communication options and a Windows CE-based runtime, this terminal delivers efficient system monitoring and simplified operator interaction.
Key Features
-
Model Number: 2711P-T12W22D8S
-
Manufacturer: Allen-Bradley (Rockwell Automation)
-
Series: PanelView Plus 7 Standard
-
Display Size: 12.1 inches (diagonal)
-
Display Type: TFT color touchscreen
-
Resolution: 1280 × 800 pixels (WXGA)
-
Aspect Ratio: 16:10 widescreen format
-
Touch Interface: Analog resistive touchscreen for gloved or stylus input
-
Processor and Memory: 1 GHz processor, 512 MB RAM, and 512 MB nonvolatile memory (approximately 80 MB available for user applications)
-
Operating System: Microsoft Windows CE 6.0
-
Supported Software: FactoryTalk View Machine Edition (ME)
-
Power Supply: 24 V DC nominal input
-
Communication Ports:
-
Dual Ethernet ports (10/100 Mbps, supports EtherNet/IP)
-
USB Type-A and Type-B ports
-
Serial port (RS-232) for legacy device communication
-
Mounting Type: Panel-mount enclosure design
-
Enclosure Rating: IP54/NEMA Type 12 (when properly installed)
-
Operating Temperature: 0°C to 55°C
-
Storage Temperature: -25°C to 70°C
Performance Highlights
-
Enhanced Visualization: Wide-format display with vivid color and sharp image clarity
-
Flexible Connectivity: Dual Ethernet ports allow multiple device connections and network segmentation
-
Efficient Integration: Designed for seamless communication with CompactLogix and ControlLogix controllers via EtherNet/IP
-
Reliable Design: Rugged construction ensures stability in continuous industrial operation
Applications
The 2711P-T12W22D8S is ideal for:
-
Machine-level control and process visualization
-
System diagnostics and alarm monitoring in production environments
-
Packaging, material handling, and assembly automation
-
Real-time control interfaces for manufacturing equipment
FAQ
-
Q1: What type of software is compatible with the 2711P-T12W22D8S?
A1: The terminal is compatible with FactoryTalk View Machine Edition (ME) software. -
Q2: What is the power requirement for this HMI?
A2: It operates on a 24 V DC nominal power supply. -
Q3: Does the terminal support dual Ethernet connections?
A3: Yes, it includes two Ethernet ports supporting 10/100 Mbps communication. -
Q4: What is the available user memory capacity?
A4: Approximately 80 MB of the 512 MB nonvolatile memory is available for user applications.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
