IC670ALG310-LA | GE Fanuc Field Control Analog Output Module

Product Overview

The GE Fanuc IC670ALG310-LA is an 8-channel analog output module designed for the Field Control system, providing precision voltage output for demanding industrial applications. It converts digital control signals into analog voltage outputs for actuators, control valves, drives, and instrumentation.

Built with robust isolation and 14-bit resolution, this module delivers high accuracy and stable analog signal performance. It operates efficiently across a wide DC power range and maintains precise linear output under varying load and temperature conditions.

Engineered for use in process control, motion regulation, and distributed I/O networks, the IC670ALG310-LA combines precision, reliability, and easy integration into GE Fanuc Field Control architectures.

Technical Specifications

• Manufacturer: GE Fanuc

• Product Line: Field Control

• Model Number: IC670ALG310-LA

• Product Type: 8-Channel Analog Output Module

• Output Type: Voltage output

• Number of Channels: 8 single-ended outputs

• Power Supply Range: 18–30 VDC (24 VDC typical, 5% ripple maximum)

• Power Consumption:

• 170 mA maximum from BIU power supply

• 275 mA maximum from external 18 V supply (all outputs at -10 V under minimum load)

• Output Range: -10.25 V to +10.25 V

• Resolution: 14-bit magnitude data (approx. 1.25 mV per count)

• Accuracy:

• ±0.15% of full scale at 25°C

• ±0.25% of full scale from 0°C to +55°C

• Update Time: 1.5 ms typical per channel

• Output Load: 5000 ohms minimum

• Load Capacitance: 1 µF maximum

• Isolation: 1500 VAC peak for 1 minute; 250 VAC continuous (to ground and logic)

• Operating Temperature: 0°C to 55°C ambient

• Storage Temperature: -40°C to 85°C

• Mounting: Field Control backplane slot

• Construction: Compact, shielded module with LED status indication

Key Features

• 8 voltage output channels with high precision and stability

• 14-bit resolution for fine analog signal control

• Operates over a wide 18–30 VDC supply range

• Strong 1500 VAC isolation ensures signal integrity and operator safety

• Rapid 1.5 ms update time for real-time control performance

• Compatible with GE Fanuc Field Control systems and Genius Bus configurations

• Rugged design for continuous industrial use

Applications

• Process automation and control loops

• Motion and position control in manufacturing systems

• Machine tool analog control outputs

• Energy and utility monitoring systems

• Distributed control systems (DCS) and SCADA networks

FAQ

Q1: What signal type does the IC670ALG310-LA provide?
It provides analog voltage outputs ranging from -10.25V to +10.25V per channel.

Q2: Is the module compatible with the Field Control system?
Yes, it is specifically designed for the GE Fanuc Field Control platform and integrates seamlessly with existing BIUs.

Q3: How accurate is this module under varying temperatures?
It maintains ±0.25% full-scale accuracy across 0°C to +55°C, making it suitable for industrial temperature ranges.

Q4: Can it operate with both internal and external power sources?
Yes, it supports both BIU-supplied and external 24V DC power, providing flexibility for system design.
