Product Details
Interface Description
The 2711P-B10C4D1 is a high-performance human-machine interface (HMI) from the PanelView Plus 1000 series, featuring a dual-input design that combines a 10.4-inch touchscreen with a full tactile keypad. This terminal is engineered for complex industrial monitoring and control, providing operators with a high-visibility color active-matrix TFT display. Designed for 24V DC environments, it serves as a robust visualization solution for local-station or distributed network applications.
Technical Specifications
-
Manufacturer: Allen-Bradley / Rockwell Automation
-
Model Number: 2711P-B10C4D1
-
Product Line: PanelView Plus 1000
-
Display Type: Color Active Matrix TFT LCD
-
Screen Size: 10.4 inches (211 x 158 mm active area)
-
Native Resolution: 640 x 480 VGA
-
Operator Input: Analog Resistive Touchscreen and Stainless-steel Domed Keypad
-
Keypad Layout: 32 function keys (F1-F16, K1-K16), Numeric entry, and Navigation arrows
-
Backlight Life: CCFL; 50,000 hours minimum (replaceable)
-
Input Voltage: 24V DC (Range: 18–32V DC)
-
Power Consumption: 70 Watts maximum
-
Internal Memory: 64 MB total (typically 32MB Flash / 32MB RAM)
-
Communication Interfaces: Integrated Ethernet and RS-232 ports
-
External Expansion: Supports CompactFlash cards and USB peripherals
-
Weight: 1.81 kg (4.00 lbs)
System Integration and Compatibility
The 2711P-B10C4D1 provides flexible communication capabilities via its modular design. While the base unit includes Ethernet and Serial ports, it supports additional communication modules for DH+, Remote I/O (RIO), and DH-485 networks. This model is optimized for use with FactoryTalk View Studio Machine Edition software, allowing for seamless tag integration with Logix-based controllers. Due to its "Discontinued" lifecycle status, it remains a critical component for maintaining legacy systems where precise keypad interaction and touch flexibility are both required.
Functional Comparison: B10C vs. K10C vs. T10C
-
2711P-B10C4D1: Features both Keypad and Touchscreen inputs for maximum versatility in oily or gloved-hand environments.
-
2711P-K10C4D1: Features Keypad-only input, preferred for applications requiring high tactile feedback and durability against screen wear.
-
2711P-T10C4D1: Features Touchscreen-only input, providing a larger virtual workspace and a more modern, streamlined user interface.
Frequently Asked Questions
Can the backlight be replaced on the 2711P-B10C4D1?Yes, the CCFL backlight is a field-replaceable component, extending the service life of the terminal beyond the initial 50,000-hour rating.
What software is required to program this terminal?Configuration is performed using FactoryTalk View Studio Machine Edition (ME) software. Ensure the firmware version of the hardware is compatible with your software project version.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
