Product Description
The 1756SC-IF8H by Allen-Bradley is an advanced 8-channel analog input module designed for ControlLogix systems. It provides high-precision measurements while supporting HART communication for enhanced device monitoring, diagnostics, and configuration. Ideal for process control, instrumentation, and automation applications requiring reliable and accurate analog input readings.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model: 1756SC-IF8H
-
Product Line: ControlLogix
-
Module Type: 8-Channel Analog Input Module
-
Number of Channels: 8 differential inputs
-
Input Types: Current (0–20 mA, 4–20 mA), Voltage (0–5V, 1–5V, 0–10V, ±10V)
-
Resolution: 16–21 bits depending on input range
-
Accuracy: ±0.05% of range for voltage, ±0.15% for current
-
Update Times: 18–488 ms (all channels)
-
HART Communication: Full support for dynamic variables, device diagnostics, and configuration
-
Isolation: 2550 VDC field-to-backplane, 500 VDC channel-to-channel
-
Power Consumption: 300 mA @ 5V, 70 mA @ 24V
-
Operating Temperature: 0°C to 60°C
-
Storage Temperature: -40°C to 85°C
-
Humidity: 5–95% (non-condensing)
Key Features
-
HART Master Capability: Enables real-time communication with HART-enabled field devices for monitoring and configuration.
-
High Accuracy Measurement: Ensures reliable data acquisition in critical applications.
-
Advanced Filtering Options: Selectable filter frequencies optimize signal quality.
-
Robust Electrical Isolation: Protects against noise and transient spikes.
-
Compact ControlLogix Design: Integrates seamlessly into standard chassis for space efficiency.
Applications
-
Process control and monitoring
-
Industrial instrumentation
-
Chemical, oil & gas, and energy sectors
-
High-precision analog measurements for factory automation
FAQ / Model Comparison
-
Q: Can the 1756SC-IF8H be used with non-HART devices?
A: Yes, it functions fully as a standard analog input module without HART communication. -
Q: How does it differ from 1756-IF8?
A: The 1756SC-IF8H supports HART communication and provides higher isolation and advanced filtering options.
