Product Details
Overview
The IC693CPU363 serves as the central processing unit for Series 90-30 PLC systems, executing user programs, managing logic operations, and facilitating communication between modules, engineered for high reliability and performance in industrial automation environments.
Technical Specifications
-
Manufacturer: GE Fanuc Emerson
-
Model / Part Number: IC693CPU363
-
Product Type: Single-Slot CPU Module
-
Series: Series 90-30
-
Processor: 80386EX, 25 MHz
-
Power Supply: +5 VDC, 890 mA
-
User Program Memory: 240 KB RAM, 256 KB total memory
-
Operating Temperature: 0–60°C (32–140°F)
-
Storage Temperature: -40–85°C (-40–185°F)
-
Discrete Input Points (%I): 2,048 points
-
Discrete Output Points (%Q): 2,048 points
-
Discrete Global Memory (%G): 1,280 bits
-
Internal Coils (%M): 4,096 bits
-
Temporary Output Coils (%T): 256 bits
-
System Status References (%S): 128 bits
-
Register Memory: Configurable in 128-word increments from 128 to 16,384 words
-
Analog Inputs (%AI): Configurable 128–16,384 words
-
Analog Outputs (%AQ): Configurable 128–16,384 words
-
Timers / Counters: 2,000
-
Scan Rate: 0.22 ms per 1K Boolean logic points
-
Communication Ports: RS-232C, RS-485, Ethernet support
-
I/O Points Support: Up to 4,096 combined input/output points
Applications
-
Core controller for large-scale Series 90-30 PLC systems
-
Complex logic control and process automation
-
Integration with multiple I/O modules for monitoring and control
FAQ
Q: How many expansion baseplates can the IC693CPU363 support?
A: It can manage up to eight baseplates including the CPU baseplate.
Q: What type of processor does this module use?
A: It is powered by a 25 MHz 80386EX processor for high-speed program execution.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
