Honeywell TC-PCIC01K | 5 Mbps ControlNet Interface

Overview:

The Honeywell TC-PCIC01K is a high-performance ControlNet Interface Module designed for seamless integration within Honeywell’s industrial control platforms. This module ensures reliable communication for ControlNet-based systems and provides a robust solution for connecting devices in automated environments. With a 5 Mbps data rate and DB9 male connector, it supports a range of industrial applications, ensuring minimal downtime and high data integrity.

Technical Specifications:

• Manufacturer: Honeywell

• Model Number: TC-PCIC01K

• Product Type: ControlNet Interface Module

• Communication Protocol: ControlNet

• Data Rate: 5 Mbps

• Connector Type: DB9 male for ControlNet cable

• Power Supply: Powered through the PCI bus

• Operating Temperature: -20°C to +70°C

• Storage Temperature: -40°C to +85°C

• Humidity: 5% to 95%, non-condensing

• Vibration Resistance: 5 Hz to 500 Hz, 0.5 g RMS

• Shock Resistance: 10 g, 11 ms duration

• Weight: 0.75 lbs

Features:

• High-Speed Communication: Offers a 5 Mbps data rate for fast and reliable data transfer.

• Robust Integration: Compatible with Honeywell’s industrial automation systems, ensuring smooth connectivity.

• Compact & Reliable: Small form factor with DB9 male connector for easy integration into existing systems.

• Temperature and Environmental Resistance: Built to operate in temperatures ranging from -20°C to +70°C, it can withstand harsh industrial environments.

• Shock and Vibration Tolerance: Vibration resistance of 0.5 g RMS and shock resistance of 10 g, ensuring operational stability even in rugged conditions.

• PCI Bus Powered: Eliminates the need for external power supplies, simplifying installation and reducing operational complexity.

Applications:

The Honeywell TC-PCIC01K ControlNet Interface Module is ideal for industrial environments where reliable and fast network communication is critical. Commonly used in applications such as:

• Manufacturing Automation

• Process Control

• Machine Control Systems

• Energy Management

Frequently Asked Questions (FAQ):

Q: What type of connector does the TC-PCIC01K use?
A: The TC-PCIC01K uses a DB9 male connector for ControlNet cable connections, ensuring a secure and reliable connection.

Q: Can this module be used in extreme temperatures?
A: Yes, it operates within a temperature range of -20°C to +70°C, making it suitable for most industrial environments.

Q: How does this module connect to the control system?
A: The module is powered through the PCI bus, simplifying its integration into systems without requiring separate power supplies.
