Bently Nevada 176449-04 3500/45 Position Monitor Module

Description

Bently Nevada 176449‑04 is a 3500/45 Position Monitor Module designed to measure shaft position, vibration, and phase reference in rotating machinery, providing continuous monitoring and protection.

Specifications

• Part Number: 176449‑04

• Model: 3500/45 Position Monitor

• Manufacturer: Bently Nevada

• Measurement Types: Shaft position, vibration, and phase reference

• Input Channels: 4 independent channels

• Sensor Compatibility: Proximitor probes and other displacement transducers

• Alarm Capability: Configurable alert and danger thresholds

• Communication: Interfaces with 3500 rack and System 1 software

• Operating Temperature: −30°C to +65°C

• Dimensions: 241.3 mm × 24.4 mm × 241.8 mm

• Weight: Approx. 0.9 kg

• System Compatibility: Designed for Bently Nevada 3500 Series racks

Features

• Multi‑Channel Monitoring: Provides four channels for comprehensive shaft position and vibration measurements

• Phase Reference Capability: Enables precise diagnostics and machinery balancing applications

• Real‑Time Protection: Continuous monitoring with configurable alarms for early fault detection

• System Integration: Seamlessly connects with 3500 racks and System 1 software

• High Reliability: Built for harsh industrial environments and continuous operation

• Flexible Configuration: Supports multiple probe types and measurement setups

• Compact Design: Fits standard 3500 rack slots for easy installation
