Product Details
Overview
The 1769-L30ER-NSE is a CompactLogix processor module by Allen-Bradley featuring dual Ethernet ports with Device Level Ring (DLR) support for redundant network configurations. Designed for reliable and high-speed control in CompactLogix systems, it integrates serial communication capabilities and expandable memory for versatile industrial applications.
Technical Specifications
-
Brand & Model: Allen-Bradley 1769-L30ER-NSE
-
Product Type: CompactLogix Processor Module
-
Product Line: CompactLogix
-
Module Type: Processor/Controller
-
Memory: 1 MB
-
Communication Interfaces: Dual Ethernet with DLR, Serial port
-
Supported Series: A and B
-
Replacement Terminal Block: 1769-RTBN18
-
Wire Type: Copper rated 90°C
-
Solid Wire Size: 22–14 AWG
-
Stranded Wire Size: 22–16 AWG
-
Weight: 12 lbs (5.44 kg)
-
Mounting Options: Panel and DIN Rail
Features
-
Dual Ethernet ports with Device Level Ring (DLR) for network redundancy
-
High-reliability processor module for CompactLogix 5370 L1 systems
-
Compatible with A and B series modules
-
Easy wiring and robust terminal blocks for industrial applications
Applications
Ideal for CompactLogix automation systems, machine control, and industrial networks requiring dual Ethernet connectivity with DLR redundancy.
FAQ
Q: What is DLR on the 1769-L30ER-NSE?
A: Device Level Ring provides redundant Ethernet communication, allowing continued operation if one network path fails.
Q: Which wire sizes are compatible?
A: Solid wires 22–14 AWG, stranded wires 22–16 AWG, copper rated 90°C.
Q: Can it replace earlier CompactLogix modules?
A: Yes, compatible with A and B series modules.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
