Allen Bradley 6181H-12FPXPHDC VersaView 1200H Industrial Computer Terminal

Product Overview

The Allen Bradley 6181H-12FPXPHDC functions as a robust, integrated industrial computer terminal within the VersaView 1200H series. It combines a high-resolution 12.1-inch full-color TFT display with a dedicated Intel Pentium III processing engine to handle complex HMI applications and data-intensive industrial software. This terminal provides a high-reliability interface for machine-level monitoring and control, bridging the gap between raw factory data and operator visualization. Designed for localized processing, it executes demanding automation scripts and visualization tasks directly at the point of operation.

Technical Specifications

Engineering Advantages

• Dual Power Versatility: The 6181H-12FPXPHDC supports both wide-range AC (90–264V) and 24V DC (18–32V) power inputs. This flexibility allows engineers to standardize on a single hardware model regardless of the local power infrastructure available in the control cabinet, simplifying spare parts inventory.

• Precision Touch Navigation: The industrial-grade touchscreen facilitates intuitive system navigation and eliminates the need for external keyboards or mice in cramped environments. The resistive technology ensures accurate command registration even when operators wear heavy industrial gloves.

• Ruggedized Thermal Management: The chassis design dissipates heat efficiently without relying on high-maintenance external filters. This structural engineering protects the Intel Pentium III processor and internal components from the thermal stress common in sealed NEMA-rated enclosures.

• Extensive Legacy Connectivity: Dual RS-232 serial ports allow the terminal to communicate directly with legacy PLC-5, SLC 500, or third-party serial devices. Simultaneously, the USB 2.0 ports provide high-speed data transfer and peripheral support for modern industrial tools.

• Vibration and Impact Resistance: Engineered for the factory floor, the 6181H-12FPXPHDC withstands constant mechanical vibration and incidental impacts. The 15-lb heavy-duty construction prevents component displacement and ensures continuous operation near high-vibration machinery like stamping presses or large motors.

FAQs

• Is the 6181H-12FPXPHDC 100% Brand New?

  Yes. We supply this terminal in 100% Brand New, original factory condition. It arrives in its original Allen Bradley packaging, ensuring zero previous run-time and maximum service life for your critical applications.

• Can this unit run modern Windows-based HMI software?

  The 6181H-12FPXPHDC utilizes an Intel Pentium III architecture with 256 MB RAM. It optimally runs Windows-based environments specifically designed for this era of industrial computing, such as FactoryTalk View ME or legacy SCADA nodes. Verify your software's minimum hardware requirements before installation.

• How do I install the unit in a control panel?

  The terminal supports panel mounting. You must follow the provided cutout dimensions precisely to ensure a NEMA-compliant seal. Use the included mounting clips to apply uniform pressure across the gasket, protecting the internal electronics from dust and moisture ingress.

• Does the unit support external monitors?

  This model focuses on its integrated 12.1" TFT display. For applications requiring dual-screen visualization or remote monitoring, consult the system's video output options located on the rear I/O panel.
