Product Details
Description
The TY801K01 Shunt Stick provides a secure electrical bridge on S800 I/O termination units for testing, commissioning, or configuring signal loops. It ensures proper grounding, prevents floating potentials, and supports accurate diagnostics within the AC 800M system.
Specifications
-
Manufacturer: ABB
-
Country of Origin: Sweden
-
Model Number: TY801K01
-
Order Number: 3BSE023607R1
-
Product Series: S800 I/O
-
Component Type: Shunt / Bridging Accessory
-
Construction: High-conductivity contacts with industrial-grade polymer housing
-
Compatibility: Standard S800 I/O Module Termination Units (MTUs)
Features
-
Precision Connectivity: Provides a reliable, low-resistance electrical bridge for accurate signal grounding and referencing.
-
Mechanical Compatibility: Designed with a specific form factor to ensure a perfect fit into S800 system hardware without the risk of loose connections.
-
System Stability: Helps eliminate electrical noise and floating signals by establishing a firm common reference point for I/O channels.
-
Tool-Free Installation: Designed for easy manual insertion and removal during system setup or diagnostic procedures.
-
Durable Construction: Manufactured to withstand the vibrations and thermal variations typical of industrial control cabinets and junction boxes.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
