ABB IMCKN01 Bailey Infi 90 Clock Network Module

Description

The ABB IMCKN01 is a specialized timing and synchronization module designed for the Bailey Infi 90 and Network 90 distributed control systems. It serves as a master or slave clock reference within the control network, ensuring all distributed processors and I/O units maintain a unified timebase. This precision is vital for accurate sequence-of-events recording, synchronized data logging, and the coordinated execution of time-critical automation logic across multiple system nodes.

Specifications

• Brand: ABB Bailey

• Model Number: IMCKN01

• Product Type: Clock Network Module

• Series: Infi 90 / Network 90

• Product Net Weight: 0.51 kg (1.12 lbs)

• Gross Weight: 0.64 kg (1.41 lbs)

• Product Height: 177.8 mm (7.0 inches)

• Product Width: 35.6 mm (1.4 inches)

• Product Depth: 298.5 mm (11.75 inches)

• Power Requirements: Supplied via the module mounting unit backplane

Features

• Network-Wide Synchronization: Distributes a consistent clock signal across the CNET to eliminate time drift between different processing modules.

• SOE Accuracy: Facilitates high-resolution Sequence of Events monitoring, enabling precise post-fault analysis and troubleshooting in power and process plants.

• Flexible Clock Hierarchy: Configurable to operate as a system master clock or to synchronize with an external timing source for plant-wide consistency.

• System Integrity: Provides the heartbeat for communication protocols, ensuring stable data packet exchanges and reducing network jitter.

• Fault Diagnostics: Includes front-facing status indicators that allow for immediate verification of synchronization state and module hardware health.
