ABB CI871K01 3BSE056767R1 AC 800M PROFINET IO Communication Interface Kit

Description

The CI871K01 3BSE056767R1 provides a standardized Ethernet-based communication path for modern automation systems. This kit consists of the CI871 communication module and the TP871 terminal baseplate, facilitating direct mounting on the CEX-Bus expansion rail. It supports the PROFINET IO RT (Real-Time) protocol, ensuring deterministic signal updates required for time-sensitive process control. The interface is engineered for high-availability applications, supporting redundant configurations to maintain network stability in the event of hardware or cable failure.

Specifications

• Manufacturer: ABB

• Country of Origin: Switzerland

• Model Number: CI867AK01 (3BSE092689R1)

• Product Type: PROFINET IO Interface Kit

• Protocol: PROFINET IO RT

• Hardware Interface: CEX-Bus (Communication Expansion)

• Kit Components: CI871 Module and TP871 Baseplate

• Transmission Speed: 100 Mbit/s (Full Duplex)

• Node Capacity: Supports up to 128 PROFINET IO devices

• Redundancy: Supports 1:1 hardware redundancy

• Power Supply: 24 VDC (internal via CEX-Bus)

• Weight: 0.73 kg

Features

• Real-Time Data Exchange: Utilizes the PROFINET IO RT protocol to provide the high-speed, deterministic communication necessary for process automation.

• Large Device Capacity: Capable of managing up to 128 remote devices, making it suitable for large-scale distributed I/O architectures.

• Redundant System Architecture: Fully supports deployment in redundant pairs to ensure maximum uptime for critical infrastructure.

• Advanced Diagnostics: Provides acyclic communication channels for device configuration, parameterization, and detailed fault reporting.

• Integrated Protection: Built-in galvanic isolation ensures the AC 800M controller is shielded from electrical noise and network transients.

• Simple Installation: The included baseplate ensures a secure mechanical and electrical connection to the controller expansion bus via DIN rail.
