2094-BC01-M01-M | Allen-Bradley | Kinetix 6200 Integrated Axis Module

Product Overview

The Allen-Bradley 2094-BC01-M01-M serves as the central power and control anchor for the Kinetix 6200 multi-axis servo system. This Integrated Axis Module (IAM) combines a high-efficiency power converter with a high-performance inverter in a single hardware footprint. We supply this unit as 100% Brand New original factory stock. It converts 460V AC three-phase input into a stable DC bus voltage to power itself and additional follower axes, streamlining motion control for complex packaging, converting, and assembly applications.

Technical Specifications

Engineering Advantages

• Consolidated Power Architecture: The 2094-BC01-M01-M eliminates the need for separate power supplies and drive units. By integrating the converter and inverter, this module reduces cabinet space requirements and simplifies the DC bus connection for downstream follower modules.

• Modular Safety and Control: The "-M" suffix designates a modular design. This allows engineers to install specific control headers (Sercos or EtherNet/IP) and safety modules directly onto the power base. This flexibility enables rapid hardware updates without replacing the entire high-power section.

• High-Capacitance Energy Management: A robust 4585 $\mu$F bus capacitance handles aggressive deceleration cycles. This internal storage absorbs regenerative energy from the motor, preventing overvoltage trips during high-speed indexing or rapid emergency stops.

• Efficient Heat Dissipation: The module utilizes an optimized airflow path to maintain its 9A rating up to 50 °C. This thermal management ensures consistent performance in dense control cabinets where heat buildup typically forces the derating of standard drives.

• Simplified Power Rail Mounting: The unit snaps directly onto the 2094 power rail. This connection method establishes the DC bus and control power links automatically, removing the risk of wiring errors associated with manual bus bar installation.

FAQs

• Does the 2094-BC01-M01-M include the control header?

  No. This part number represents the Integrated Axis Module power base. You must purchase the appropriate Kinetix 6200 control module (e.g., 2094-EN02D-M01-S0) separately to enable communication and logic functions.

• Can I replace an older Kinetix 6000 IAM with this 6200 model?

  Yes, the 2094-BC01-M01-M provides a migration path from the Kinetix 6000 series. However, ensure your software (Studio 5000/Logix Designer) supports the Kinetix 6200 profile and verify that your control header is compatible with the new power base.

• What is the significance of the "BC" in the part number?

  The "BC" indicates a 400V-class power module designed for 360–480V AC three-phase input. Do not connect this module to a 200V-class power source, as it will fail to reach the required DC bus threshold.

• Are these units factory-sealed?

  We guarantee every 2094-BC01-M01-M is 100% Brand New in its original Allen-Bradley packaging. Every unit arrives with intact factory seals, ensuring you receive the maximum service life from the internal power electronics and capacitors.
