Description
The ABB 3BHB003387R0101, 3BHL000385P0101, and 5SHX0845F0001 IGCT Power Modules are designed for demanding industrial environments requiring precise power control and extended durability. These modules combine the robustness of thyristors with the fast-switching capability of IGBTs, providing high-efficiency performance for high-voltage applications and heavy-duty motor drives.
With a compact footprint and advanced thermal management, the modules maintain reliable operation under high electrical and thermal stress, making them ideal for power conversion, HVDC transmission, renewable energy systems, and industrial transportation solutions.
Specifications
-
Manufacturer: ABB
-
Model Numbers: 3BHB003387R0101, 3BHL000385P0101, 5SHX0845F0001
-
Product Type: IGCT Power Module
-
Dimensions (L × W × H): 100 × 100 × 100 mm
-
Weight: 1 kg
-
Operating Temperature Range: -40°C to +85°C
-
Voltage Rating: Kilovolt-level switching capable
-
Switching Technology: Integrated Gate-Commutated Thyristor (IGCT)
-
Mounting Type: Panel or screw-mounted
-
Thermal Management: Advanced cooling for continuous heavy-duty operation
-
Applications: HVDC transmission, large industrial drives, renewable energy integration, converters, inverters, and transportation systems
Features
-
Hybrid Switching Technology: Combines IGBT controllability with thyristor robustness.
-
High Reliability: Maintains long-term performance under extreme electrical and thermal stress.
-
Fast Switching: Reduces conduction losses, improving overall system efficiency.
-
Compact Footprint: Simplifies system design and reduces cabinet space requirements.
-
Wide Industrial Compatibility: Supports high-voltage, megawatt-scale motors and converters.
-
Durable Construction: Designed for harsh industrial and transportation environments.
Applications
Commonly deployed in HVDC substations, large motor drives for steel and paper industries, renewable energy inverters for wind and solar, and traction systems for rail and ship propulsion. These modules provide low-loss, high-efficiency power control in critical applications.
FAQ
Q1: How does an IGCT differ from an IGBT or conventional thyristor?
A1: IGCT technology merges the ruggedness of a thyristor with the controllability of an IGBT, providing higher efficiency and fast switching for high-power applications.
Q2: Which industries use this ABB IGCT module?
A2: It is widely applied in HVDC transmission, heavy industrial drives, renewable energy systems, and transportation networks.
Q3: What are the physical dimensions and weight?
A3: The module measures 100 × 100 × 100 mm and weighs 1 kg.
Q4: Can it handle high-voltage applications?
A4: Yes, it is engineered for kilovolt-level switching in megawatt-scale systems.
