Product Details
Configured for high-speed fieldbus communication in DeltaV M-Series control platforms, the Emerson VE4014 (VE4014 Interface Card) provides direct physical and electrical execution of Profibus DP protocol exchange. This module acts as a dedicated communication gateway to manage data transmission between the controller and localized field devices.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | VE4014 |
| Brand | Emerson |
| Origin | N/A |
| Weight | 0.32 kg (0.71 lbs) |
| Dimensions | Standard M-Series Form Factor |
| Operating Temp | Standard Industrial Ambient |
| Power Consumption | 600 mA at 12 VDC |
| Communication Ports | 1 Port (Profibus DP) |
Deterministic Network Connectivity
The module manages PROFIBUS DP network traffic to ensure deterministic data transfer between the M-Series controller and peripheral field instruments. The integration utilizes a single physical port interface to handle cyclic and acyclic communication cycles. Firmware compatibility ensures synchronization with the system backplane bus communication velocity, allowing for precise timing in process control loops. The card supports standard baud rate configurations to optimize network throughput and minimize latency during high-density I/O polling operations.
Frequently Asked Questions
Q: Does this module support redundant network configurations?
A: The VE4014 is designed for specific M-Series architectures. When configured in redundant pairings, the control system manages the switchover logic to ensure continuous communication with the fieldbus segment if the primary card fails.
Q: Is this module hot-swappable during system operation?
A: Yes, the VE4014 supports hot-swapping within a powered DeltaV M-Series carrier. Ensure the corresponding I/O channel is inhibited in the control software to prevent process disturbances before extraction.
Field Installation Guidelines
- Mounting: Insert the module into the designated slot on the M-Series I/O carrier. Apply firm, even pressure until the locking tabs snap into position. Ensure the card is fully seated to maintain robust backplane connection.
- Grounding: Ensure the I/O carrier chassis is properly bonded to the control cabinet ground bus to minimize noise susceptibility on the Profibus data lines.
- Wiring: Utilize shielded, twisted-pair cable specifically rated for Profibus DP (typically violet jacket) to prevent EMI/RFI interference. Keep the total cable segment length within the limitations of the selected baud rate to avoid signal attenuation.
- Termination: Ensure correct physical termination resistors are applied at both ends of the Profibus segment to prevent signal reflections.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
