ProSoft MVI56E-MCMXT ControlLogix Modbus RTU/ASCII Communication Module

Product Description

The MVI56E-MCMXT module from ProSoft Technology is a Modbus communication interface designed for Allen Bradley ControlLogix systems. Supporting both RTU and ASCII modes, it provides reliable serial communication with industrial devices, offering flexible configuration options for baud rate, parity, stop bits, and RTS timing delays.

Key Specifications

• Manufacturer: Allen Bradley / ProSoft Technology

• Model: MVI56E-MCMXT

• Part Number: MVI56E-MCMXT

• Product Type: Modbus Communication Module

• Product Line: ControlLogix

• Baud Rate: 110–115,200 baud

• Stop Bits: 1 or 2

• Parity Options: None, Even, Odd

• RTS Timing Delays: 0–65,535 ms configurable

• Modbus Modes: RTU (binary with CRC-16), ASCII (with LRC error checking)

• Operating Temperature: 0–60°C (32–140°F)

• Storage Temperature: –40–85°C (–40–185°F)

• Shipping Weight: 2 kg

Core Features

• Supports Modbus RTU and ASCII communication modes

• Flexible configuration for baud rate, parity, stop bits, and timing delays

• Designed for ControlLogix systems with enhanced reliability

• Wide operating temperature range for industrial environments

• Compact design with robust communication capabilities

Application Scenarios

• Integration of Modbus RTU/ASCII devices into ControlLogix systems

• SCADA and distributed control systems requiring Modbus communication

• Industrial automation setups in manufacturing, energy, and processing industries

FAQ

• Q: What Modbus modes are supported?  A: RTU (binary with CRC-16) and ASCII (with LRC error checking).

• Q: What is the maximum baud rate supported?  A: Up to 115,200 baud.

• Q: Can RTS timing delays be configured?  A: Yes, from 0 to 65,535 milliseconds.
