Honeywell 51305482-105 Ethernet CableHoneywell 51305482-105 Ethernet CableHoneywell 51305482-105 Ethernet Cable
Honeywell 51305482-105 Ethernet Cable
Honeywell 51305482-105 Ethernet Cable
Honeywell 51305482-105 Ethernet Cable

Honeywell 51305482-105 Ethernet Cable


Only 10 left - Selling fast

PRODUCT SKU : 51305482-105

PRODUCT TYPE : Communication Cables

PRODUCT VENDOR : Honeywell


  • 100% Genuine Parts – Risk-Free 30-Day Returns
  • 1-Year Warranty & Expert Support for Every Order

Product Details

Configured for 100BASE-T data transmission in Experion PKS networks, the Honeywell 51305482-105 (51305482-105 Ethernet Cable) provides direct physical execution for industrial automation nodes.

Hardware Specifications

Parameter Specification
Model 51305482-105
Brand Honeywell
Origin USA
Weight 13.6 lbs (6.17 kg)
Dimensions Factory standard assembly length
Operating Temp -40 to +70 deg C
Power Consumption Passive cabling assembly
Cable Type 100BASE-T Ethernet
Connector Type RJ45
Jacket Material Polyvinyl chloride (PVC) with foil shielding
Conductor Structure 4 twisted pairs, solid core with XLPE insulation
Pull Strength Up to 70 kg (150 lbs)

4-20 mA HART Loop & Channel-to-Channel Isolation Characteristics

The foil-shielded 4 twisted pair construction mitigates high-frequency noise and electromagnetic interference across industrial communications. Maintaining consistent impedance across conductor pairs preserves channel-to-channel isolation when running along control cabinets and field wireways adjacent to 4-20 mA HART loop signal cabling. This low-capacitance design minimizes cross-talk, protecting deterministic Ethernet packet transfer from signal degradation caused by neighboring analog I/O wiring.

Frequently Asked Questions

Q: Does physical disconnection of the 51305482-105 cable support hot-swapping during active operation?

A: Yes, physical hot-swap disconnection is supported, provided network logic accounts for temporary loss of communication on the affected network segment.

Q: What grounding procedure should be used for the integrated foil shield?

A: The foil shield drain wire must terminate at the designated panel ground terminal on one end to avoid ground loop currents while suppressing high-frequency interference.

Q: What precautions prevent physical damage during cable routing?

A: Do not exceed the maximum pull strength rating of 70 kg (150 lbs) and maintain standard minimum bend radius guidelines during installation to prevent conductor deformation.

Field Installation Guidelines

  1. Inspect the PVC outer jacket and RJ45 connectors for physical defects before installation.
  2. Route the cable through dedicated low-voltage wireways, maintaining separation from high-voltage AC power distribution.
  3. Observe minimum bend radius limits during pull-through to protect the internal XLPE insulation and solid core conductors.
  4. Ensure RJ45 connector latches seat fully into the target interface port with a firm tactile click.
  5. Verify proper drain wire grounding at the termination cabinet according to system layout specifications prior to commissioning.

Additional Information

  • 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
  • 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
  • 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
  • Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
  • Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
  • Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
