Product Details
The Honeywell 51202901-400, also cataloged as the 51202901 PLC Connection Cable, operates as a dedicated hardware component for physical point-to-point signal interconnection within Honeywell process control networks. The assembly establishes low-impedance electrical signal paths directly between processing modules and termination panels to execute real-time control link communication.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51202901-400 |
| Brand | Honeywell |
| Revision | Rev. B |
| Origin | USA |
| Weight | 80 g |
| Dimensions | Standard industrial rack-enclosure length footprint |
| Operating Temp | Up to 105 deg C rating |
| Power Consumption | Passive component (Zero active load) |
| Wire Gauge | 10 AWG (Xinya) |
| Insulation Type | AWM 1015 / VW-1 |
| Voltage Rating | 600 V |
| Certification | E170689 |
Honeywell DCS Channel-to-Channel Isolation Parameters
The connection cable utilizing AWM 1015 VW-1 insulated conductors maintains solid physical dielectric separation across internal wiring paths to support standardized channel-to-channel isolation limits. The 600 V rated compound layer blocks high common-mode voltage spikes and suppresses inductive cross-talk between adjacent signal conductors, ensuring clean physical data delivery across distributed control system environments.
Frequently Asked Questions
Q: Can this PLC connection cable be detached while the connected control loops are fully energized?
A: No, standard electrical safety regulations require the associated PLC modules and termination points to be fully de-energized before unlatching the connection assembly to prevent line arcing or data corruption.
Q: What is the maximum voltage threshold supported by the cable insulation?
A: The physical wire insulation is rated for a continuous dielectric breakdown barrier of up to 600 V at temperatures reaching 105 deg C.
Field Installation Guidelines
- Route the 10 AWG connection cable through designated low-voltage wire trays, ensuring isolation from active AC power lines to minimize external noise coupling.
- Observe minimum bending radius limits during structural positioning to prevent mechanical strain or micro-fractures in the internal copper strands.
- Ensure the modular connection ends are squared up completely and fully seated into the mating terminal sockets prior to securing any outer strain reliefs.
- Verify that the general shield drain wires are tied securely to the main local low-impedance instrument enclosure ground bar.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
