Product Details
Product Description
The Allen-Bradley 1746-OX8 is a digital contact output module for the SLC 500 series. It provides eight normally open relay contact outputs, designed for both AC and DC voltage operation. With individually isolated high-current relay outputs, it is suitable for applications requiring reliable switching of mixed voltage signals.
Technical Specifications
-
Manufacturer Allen-Bradley
-
Category PLCs
-
Product Line SLC 500
-
Part Number 1746-OX8
-
Weight 1.00 lbs (0.45 kg)
-
Module Type Digital contact output module
-
Number of Outputs 8 relay outputs (N.O. contacts)
-
Operating Voltage Range 5–265 VAC or 5–125 VDC
-
Current per Output (120 VAC) 3 A
-
Current per Output (24 VDC) 1.2 A
-
Backplane Current Draw 85–90 mA
-
Step Response 60 ms input, 2.5 ms output
-
Operating Shock Resistance 10 g
-
Application Type Individually isolated, high-current relay switching
Application Scenarios
-
Switching AC and DC loads in mixed-voltage environments
-
Industrial control systems requiring isolated relay outputs
-
Applications needing high-current relay contacts for motor starters, solenoids, or lighting control
FAQ
Q: How many outputs does the 1746-OX8 provide? A: It provides 8 normally open relay contact outputs.
Q: What is the maximum current per output? A: 3 A at 120 VAC and 1.2 A at 24 VDC.
Q: Are the outputs isolated? A: Yes, each relay output is individually isolated for safe operation.
Comparison with Similar Models
-
1746-OB16: Transistor output module, designed for DC loads.
-
1746-OW16: Relay output module with wider voltage range and more outputs.
-
1746-OX8: Compact relay output module with 8 isolated contacts, ideal for high-current switching.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
