Product Details
Product Description
The Allen Bradley ControlLogix 1756-IF6CIS is a high-performance analog input module designed for precision current measurement in industrial automation systems. Built with isolated channels and sigma-delta conversion technology, it ensures reliable signal integrity and accurate data acquisition across demanding applications.
Key Technical Specifications
| Attribute | Details |
|---|---|
| Manufacturer | Allen Bradley |
| Product Line | ControlLogix |
| Part Number | 1756-IF6CIS |
| Module Type | 6-Channel Analog Input, Current Sourcing |
| Input Type | Isolated current inputs |
| Conversion Method | Sigma-Delta |
| Data Format | Integer (left justified, 2’s complement) and IEEE 32-bit floating point |
| Input Range | 0–21 mA |
| Input Resolution | High-resolution current measurement |
| Backplane Current (5V) | 250 mA |
| Backplane Current (24V) | 275 mA |
| Power Dissipation | Max 5.1 W at 60 °C |
| Terminal Blocks | Compatible with 1756-TBCH and 1756-TBS6H |
| Weight | 0.81 lbs (0.37 kg) |
Application Scenarios
-
Process control systems requiring precise current input monitoring
-
Industrial automation environments with isolated signal requirements
-
Integration into ControlLogix chassis for scalable I/O expansion
FAQ
Q: What type of signals can the 1756-IF6CIS handle? A: It is designed for current sourcing signals within the 0–21 mA range.
Q: Can this module be used with other ControlLogix modules? A: Yes, it integrates seamlessly with the ControlLogix platform and supports removable terminal blocks for flexible wiring.
Q: What makes the sigma-delta conversion method beneficial? A: It provides high accuracy and noise immunity, ensuring stable readings in electrically noisy environments.
Comparable Models
-
1756-IF6I: Similar 6-channel input module but designed for current input (non-sourcing).
-
1756-IF8: Offers 8-channel analog input capability for higher density applications.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
