Product Details
The ABB DSAX 110A 3BSE018291R1, also cataloged as the DSAX 110A Analog Input/Output Board, operates as a dedicated hardware component for mixed analog signal processing within ABB Advant Master Process Control Systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DSAX 110A |
| Order Code | 3BSE018291R1 |
| Brand | ABB |
| Origin | Sweden |
| Product Type | Analog Input/Output Boards |
| Analog Inputs | 8 Channels |
| Analog Outputs | 8 Channels |
| Dimensions | 324 mm x 18 mm x 234 mm |
| Weight | 0.5 kg |
| Operating Temp | 0 to 55 deg C |
| Power Consumption | Bus-powered via subrack backplane |
| RoHS Compliance | Exempt from 2011/65/EU (RoHS) under Article 2(4) |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
Backplane Bus Communication & I/O Density Scaling
The ABB DSAX 110A board integrates 8 input channels and 8 output channels onto a single subrack card assembly, maximizing cabinet I/O density scaling. Real-time conversion circuitry processes field variable signals directly to and from the Advant Master backplane bus. Maintained firmware flash compatibility ensures synchronized cyclic updates and low communication latencies across connected controller stations.
Frequently Asked Questions
Q: What channel configuration does the DSAX 110A board provide?
A: The board provides a dual-function configuration with 8 dedicated analog input channels and 8 dedicated analog output channels.
Q: Is hot-swapping allowed for the DSAX 110A card during backplane operation?
A: Power to the subrack segment must be turned off or the target slot deactivated prior to card removal to avoid bus communication errors and voltage transients.
Field Installation Guidelines
- Power off the system rack chassis before seating or removing the DSAX 110A module.
- Align the board circuit card with the card guide rails and slide it into the slot until the backplane bus connectors seat fully.
- Fasten front retaining screws to secure the physical assembly and establish a solid chassis earth connection.
- Route input and output signal cables separately from 230 V AC / 380 V AC power lines to minimize electrical noise interference.
- Ground field cable shields at the single-point grounding bus bar located at the cabinet base.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
