Product Details
Product Description
The 1771-WI is a reliable wiring arm module designed for output connections in PLC-5 systems. It supports low-resistance signal transfer for thermocouple and other low-voltage applications, with gold-plated terminals and conformal coating to ensure long-term durability and signal integrity. The module is compatible with 1771 I/O chassis and provides precise AC/DC signal response.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model Number: 1771-WI
-
Product Type: Output Wiring Arm Module
-
Module Type: Wiring Arm
-
Max Number of I/O Points: 8
-
Number of Terminals: 18
-
Contact Plating: Gold
-
Screw Torque: 7–9 lb·in
-
Typical Application: Thermocouple, low-resistance connections
-
Protective Coating: Conformal coat
-
Required External Power: None
-
Typical AC Signal Delay (Off): 29 ± 8 ms
-
Typical DC Signal Delay (Off): 30 ± 7 ms
-
Compatible Wiring Arm: 1771-WN
-
Weight: 0.31 lbs (0.14 kg)
Key Features
-
Gold-plated contacts for minimal resistance and reliable connectivity
-
Compact rack-mountable design compatible with PLC-5 I/O chassis
-
Conformal coating protects against dust, moisture, and corrosion
-
Suitable for thermocouple and low-voltage output wiring
Applications
-
Output wiring in PLC-5 control systems
-
Low-resistance signal distribution for analog and thermocouple modules
-
Modular expansion of I/O connectivity
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
