Product Details
The Honeywell CC-TUI031, also cataloged as the CC-TUI031 Input Module, operates as a dedicated hardware component for multi-channel field signal acquisition and deterministic analog/digital processing within Honeywell Experion PKS Series C control networks.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-TUI031 |
| Brand | Honeywell |
| Origin | USA |
| Weight | 0.59 kg |
| Dimensions | 6.8 cm x 10.7 cm x 7.8 cm |
| Operating Temp | 0 deg C to 60 deg C |
| Power Consumption | Not specified |
| Module Type | Universal Input Module |
| Interface Type | Series C IOTA Mounting |
| Input Signal Types | 4-20 mA HART, Voltage, Digital Inputs |
| System Compatibility | Experion PKS C300 Controller |
4-20 mA HART Loop Protocol & Channel-to-Channel Isolation
The CC-TUI031 digitizes field transmitter signals while isolating incoming sensor loops from backplane logic power. Integrated channel-to-channel isolation networks block high common-mode voltage spikes, ground potential differences, and field-side electrical interference. Digital filtering circuits process incoming signal parameters before transmitting process variables across redundant I/O Link buses to maintain system control execution.
Frequently Asked Questions
Q: How does the CC-TUI031 protect backplane electronics from field-side ground loops?
A: Internal galvanically isolated input circuits decouple individual field wiring loops from the internal system backplane and power distribution buses.
Q: Can the CC-TUI031 be hot-swapped while the Series C rack is powered?
A: Yes, the module supports online insertion and removal (OIR) on a live IOTA baseboard without interrupting power or signal transmission on adjacent slots.
Q: What mounting infrastructure does the CC-TUI031 require?
A: The module attaches directly to a dedicated Series C Input Output Termination Assembly (IOTA) using guided card edge slots and mechanical locking tabs.
Field Installation Guidelines
- Verify that electrostatic discharge (ESD) prevention protocols are active and wear an grounded wrist strap before touching the CC-TUI031.
- Align the rear connector pins with the guide rails on the target Series C Input Output Termination Assembly (IOTA).
- Press the module vertically onto the IOTA mounting base until both top and bottom locking levers click into place.
- Separate field signal cables from high-voltage AC power lines within cabinet wire ducts to minimize electromagnetic interference.
- Connect all shield drain wires from field instrument cables directly to the master enclosure earth ground bar.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
