Product Details
The Honeywell CC-PCF091 51405047-176, also cataloged as the CC-PCF091 Control Firewall Module, operates as a dedicated hardware component for network traffic isolation and secure Fault Tolerant Ethernet (FTE) signal distribution within Experion Series C platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-PCF091 (Part Number: 51405047-176) |
| Brand | Honeywell |
| Origin | USA |
| Weight | Approx. 0.24 kg |
| Dimensions | 20 mm x 135 mm x 238 mm |
| Operating Temp | -40 deg C to +70 deg C |
| Power Consumption | Not specified |
| Module Type | Control Firewall (CF9) |
| Port Configuration | 9 ports (8 node ports + 1 uplink port) |
| Network Protocol | Fault Tolerant Ethernet (FTE) |
| Board Coating | Conformal coated PCB |
| Mounting | CF9 Input Output Termination Assembly (IOTA) |
4-20 mA HART Loop Protocol & Channel-to-Channel Isolation
The CC-PCF091 provides an 8+1 port Ethernet switching structure configured to route deterministic FTE communication links across cabinet-level Series C Field Interface Modules (FIMs) and IOTAs. Integrated hardware isolation barriers prevent electrical noise propagation, ground loops, and transient voltage spikes between interconnected network segments. The conformally coated circuit board maintains signal path integrity across high-density digital communication interfaces while suppressing un-authorized cross-network traffic.
Frequently Asked Questions
Q: How does the CC-PCF091 handle network port distribution within a Series C cabinet?
A: The module utilizes an 8-port downlink plus 1-port uplink structure (9-port total) to fan out Fault Tolerant Ethernet (FTE) signals to associated Field Interface Modules and IOTAs.
Q: Can the CC-PCF091 module be replaced online while the control system is active?
A: Yes, the module supports hot-swappable installation on its designated CF9 IOTA without disrupting adjacent Ethernet traffic or requiring system shutdown.
Q: What environmental protection is applied to the internal circuitry of the CC-PCF091?
A: The printed circuit board assembly is factory treated with conformal coating to prevent degradation from airborne chemical contamination and moisture.
Field Installation Guidelines
- Verify that cabinet electrostatic discharge (ESD) protection is connected and wear a grounded wrist strap before handling the CC-PCF091 module.
- Align the rear connector pins of the module with the guide rails on the CF9 Input Output Termination Assembly (IOTA).
- Press the module firmly onto the IOTA base until the top and bottom mechanical latching mechanisms lock securely into place.
- Route Category 5e/6 FTE Ethernet cables through designated wire channels, maintaining separation from high-voltage AC distribution lines.
- Ensure all Ethernet cable shielding is properly grounded at the cabinet entry gland plate to minimize electromagnetic interference.
