Product Details
Overview
The Allen-Bradley 1747-SDN is a DeviceNet scanner module designed to facilitate high-speed communication between a master PLC and DeviceNet devices. It is engineered for reliable integration within SLC 500 and PLC 5 systems, supporting multiple networked I/O devices while maintaining robust data transfer and minimal latency.
This module allows system architects to efficiently implement distributed DeviceNet networks, providing scalable control, real-time monitoring, and simplified network management. Its compact form factor enables seamless mounting in standard SLC 500 chassis, conserving panel space while maximizing connectivity.
Technical Specifications
-
Manufacturer: Allen-Bradley / Rockwell Automation
-
Model Number: 1747-SDN
-
Product Type: DeviceNet Scanner Module
-
Network Protocol: DeviceNet
-
Module Function: Scans and manages networked DeviceNet nodes
-
Supported Devices: Up to 64 DeviceNet nodes
-
Backplane Current Consumption: 0.25 A @ 5 V DC (typical)
-
Communication Speed: 125 kbps, 250 kbps, 500 kbps
-
Indicators: Network status LED, Module status LED
-
Mounting: Compatible with SLC 500 or PLC 5 racks
-
Operating Temperature: 0°C to 60°C (32°F to 140°F)
-
Humidity Range: 5% to 95% RH (non-condensing)
-
Dimensions: Standard SLC module size
-
Weight: 0.3 kg (0.66 lbs)
Applications
-
Integrating multiple DeviceNet nodes into SLC 500 or PLC 5 systems
-
Centralized monitoring and control of networked sensors, actuators, and motor controllers
-
Distributed I/O management for factory automation and process control
-
Scalable DeviceNet networks for complex machinery and production lines
FAQ
Q1: How many DeviceNet nodes can the 1747-SDN support?
A1: The module can scan and manage up to 64 nodes on a single DeviceNet network.
Q2: Is it compatible with SLC 500 systems?
A2: Yes, it integrates directly into SLC 500 and PLC 5 racks.
Q3: What communication speeds are supported?
A3: It supports 125 kbps, 250 kbps, and 500 kbps network speeds.
Q4: What is the operating temperature range?
A4: The module operates reliably between 0°C and 60°C (32°F to 140°F).
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
