Product Details
The Foxboro P0926ZM, also cataloged as the P0926ZM Electronic Pressure Transmitter, operates as a dedicated hardware component for direct fluid pressure measurement within industrial process loops. Utilizing internal sensing electronics powered by a 24 VDC loop circuit, it converts process line pressures spanning 0.25 psi to 10,000 psi into scaled analog and digital communication signals with a full-scale accuracy rating of 0.15%.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | P0926ZM |
| Brand | Foxboro |
| Origin | USA |
| Weight | 1.0 kg (2.2 lbs) |
| Dimensions | Standard Foxboro pressure transmitter housing |
| Operating Temp | -40 deg C to +80 deg C (-40 deg F to +176 deg F) |
| Power Consumption | Loop-powered via 24 VDC external supply |
| Pressure Measurement Range | 0.25 psi to 10,000 psi |
| Measurement Accuracy | 0.15% of full scale |
| Output Signal Protocols | 4-20 mA analog, HART, Profibus PA |
| Enclosure Protection Rating | IP66 |
Channel-to-Channel Isolation and Loop Protocol Connectivity
The Foxboro P0926ZM integrates digital signal processing circuits capable of multiplexing analog current signals with overlay digital data using 4-20 mA HART loop protocol communications or direct Profibus PA network connectivity. Internal galvanic isolation barriers prevent electrical ground loops between the process media sensing diaphragm and output loop terminals, preventing noise coupling on analog control channels.
Frequently Asked Questions
Q: What process pressure ranges are supported by the P0926ZM transmitter?
A: The transmitter measures process media pressures ranging from 0.25 psi up to 10,000 psi.
Q: What communications interface protocols are available on the P0926ZM?
A: The unit supports selectable output configurations including 4-20 mA analog current loops, HART protocol modulation, and Profibus PA fieldbus connections.
Field Installation Guidelines
Mount the P0926ZM directly to process piping or an auxiliary mounting bracket using standard process connections. Ensure the IP66-rated housing cover is fully threaded down and seals tightly against the O-ring gasket to prevent moisture ingress in harsh field environments.
Wire field connections to the internal terminal block using twisted-shielded cable pairs. Route field wiring through dedicated electrical conduit, verifying that threaded NPT conduit entries achieve a minimum of 5 full threads of engagement. Connect the cable drain shield directly to the nearest single-point panel ground bar to maintain signal integrity against high-frequency electromagnetic interference.
