Product Details
The GE DS200TCPSG1A, also cataloged as the DS200TCPS Power Supply Board, operates as a dedicated hardware component for converting 125 VDC input power into multiple regulated voltage levels within Mark V turbine control systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200TCPSG1A |
| Brand | General Electric |
| Origin | USA |
| Operating Temp | Standard industrial range |
| Power Consumption | N/A (Power supply unit) |
| Input Voltage | 125 VDC |
| Output Voltages | +5 VDC, +24 VDC, +/- 15 VDC, +/- 24 VDC |
Power Distribution and Deterministic Voltage Regulation
The DS200TCPSG1A is designed for deployment within R and I/O cores, providing essential power rails for microprocessor logic, RTD sensing, and servo valve current outputs. The board architecture features three onboard fuses for circuit protection and multiple test points for diagnostic monitoring of regulated outputs. Deterministic power delivery is maintained through physical connectors, including J1 for input power and 2PL, JC, JP1, and JP2 for daisy-chain distribution to peripheral boards such as AAHA, TCDA, and TCCA modules. The module operates without software configuration or hardware jumpers, ensuring consistent voltage output based on hardwired architecture.
Frequently Asked Questions
Q: Does the DS200TCPSG1A require field-level software configuration or jumper adjustments?
A: No. The board is designed as a plug-and-play power regulation module. It contains no software-configurable registers or hardware jumpers; all voltage transformation levels are fixed by the onboard circuitry.
Q: What are the primary diagnostic indicators available on the board?
A: The board features multiple test points for monitoring the +5 VDC, +24 VDC, and +/- 15/24 VDC output rails. If a specific voltage rail is absent, verify the integrity of the three onboard fuses and the 125 VDC input supply through connector J1.
Field Installation Guidelines
- Ensure the system rack is fully de-energized before inserting or removing the TCPS board to prevent arcing at the input and distribution connectors.
- Verify the 125 VDC input source at connector J1 prior to board activation to ensure the board operates within its design specifications.
- Handle the module by the edges and faceplate to maintain structural integrity of the daisy-chain distribution connectors (2PL, JC, JP1, JP2).
- After installation, utilize the integrated test points to confirm that all output voltage rails are within tolerance before re-establishing communication with the associated I/O and processor cores.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
