Allen-Bradley CompactLogix 1769-IQ6XOW4 Automation Controller

Overview
The 1769-IQ6XOW4 from Allen-Bradley is a CompactLogix module designed for high-performance control in automation systems. It is optimized for low power consumption while providing reliable operation in industrial environments.

Technical Specifications

• Brand & Model: Allen-Bradley 1769-IQ6XOW4

• Product Type: CompactLogix Controller Module

• Current Draw: 105 mA at 5.1 V DC, 50 mA at 24 V DC

• Maximum Heat Dissipation: 2.75 W

• Maximum Off-State Voltage: 11 V DC

• Shipping Weight: 1.5 kg

• Module Compatibility: CompactLogix Control Systems

• Installation: Rack or DIN Rail Mountable

• Operating Environment: Industrial temperature and humidity ranges

Applications
The 1769-IQ6XOW4 is suitable for use in CompactLogix automation systems for tasks such as discrete I/O control, analog signal processing, and integration with larger PLC networks. It is ideal for both standalone applications and distributed control configurations.

FAQ

Q: What is the power requirement for the 1769-IQ6XOW4?
A: It draws 105 mA at 5.1 V DC and 50 mA at 24 V DC, making it energy-efficient for standard PLC operations.

Q: Can this module operate in harsh industrial environments?
A: Yes, it is designed for standard industrial temperature and humidity ranges with robust heat dissipation.

Q: Is this module compatible with other CompactLogix controllers?
A: Yes, it integrates seamlessly with the CompactLogix series.
