Product Details
The ABB PP846A 3BSE042238R2 serves as the primary PP846A Operator Panels utilized to execute human-machine interfacing and local system parameter monitoring across ABB control system platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | PP846A |
| Order Code | 3BSE042238R2 |
| Brand | ABB |
| Origin | Sweden |
| Product Type | Operator Panels |
| Power Rating | 24 VDC industrial power input |
| Harmonic Measurement | Up to 31st harmonic voltage/current measurement capability |
| Measurement Channel | Dedicated 4th channel for neutral line leakage detection |
| Weight | 3.115 kg |
| Dimensions | Compact panel cut-out housing |
| Operating Temp | 0 to 50 deg C |
| Power Consumption | 20 W nominal |
Backplane Bus Communication & Firmware Flash Compatibility
The ABB PP846A panel communicates directly with host controllers via high-speed serial and Ethernet interface channels, enabling real-time bus polling and alarm processing. Integrated firmware flash compatibility guarantees seamless software runtime execution and synchronization across connected controller nodes without compromising panel refresh rates or deterministic network update cycles.
Frequently Asked Questions
Q: Does the PP846A operator panel support hot-swapping or live replacement?
A: No, 24 VDC primary power must be disconnected from the rear power terminal block prior to mounting, wiring, or replacing the unit.
Q: How is electrical noise suppressed on the harmonic measurement channels?
A: The panel utilizes internal isolation circuitry and shielded communication ground paths to process AC current/voltage harmonic data up to the 31st order without field interference.
Field Installation Guidelines
- Cut cabinet door panel openings according to official template dimensions before mounting the unit.
- Insert the PP846A panel into the cutout and secure all side retaining clamps evenly to maintain enclosure sealing.
- Verify that the 24 VDC power source is switched off before terminating power connections to the supply block.
- Route communication cables in shielded channels separated from high-voltage motor leads and AC power distribution lines.
- Connect the functional earth terminal on the rear chassis directly to the main enclosure earth ground bar using a low-impedance conductor.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
