ABB PFEA111-20 3BSE050090R20 Stable Tension Electronics Control Module

Description

The ABB PFEA111-20 3BSE050090R20 Tension Electronics Control Module is a stable and reliable unit engineered for precise web tension measurement and regulation in ABB industrial automation systems.

Specifications

• Manufacturer: ABB

• Origin: Sweden

• Model Number: PFEA111-20 / 3BSE050090R20

• Type: Tension Electronics Control Module

• Inputs: 2 load cell inputs

• Outputs: Voltage and current outputs A+B with adjustable filtering

• Power Supply: 24 V DC, 8 W consumption

• Fuse: Slow blow, 2 A, 250 V

• Display: 2 × 16 character LCD showing sum, difference, or individual load cell signals

• Protection Class: IP65 (NEMA 4)

• Versions: DIN rail and closed housing options

• Net Weight: ~1 kg

• Application: Web tension measurement and regulation in ABB force measurement systems

Features

• Stable Tension Control: Dual load cell inputs ensure precise monitoring and regulation of web tension

• Flexible Outputs: Voltage and current outputs with adjustable filtering for smooth integration

• Compact and Rugged: IP65 protection guarantees durability in harsh industrial environments

• User-Friendly Display: Real-time visualization of load cell signals for easy diagnostics

• Versatile Installation: Available in DIN rail and closed housing versions for different setups

• Low Maintenance: Long service life with minimal upkeep requirements
