ABB INLIM03 Bailey Infi 90 Loop Interface Module

Description

The ABB INLIM03 is a high-performance Loop Interface Module designed for the Bailey Infi 90 and Network 90 distributed control systems. This module serves as the primary communication bridge between the Plant Loop or Network 90 Loop and the module bus. It facilitates the transparent exchange of process data, configuration parameters, and diagnostic information across the control architecture. By managing high-speed data packet routing, the INLIM03 ensures that distributed processing units can interact with the broader network with high determinism and reliability.

Specifications

• Brand: ABB Bailey

• Model Number: INLIM03

• Product Type: Loop Interface Module

• Series: Infi 90 / Network 90

• Product Net Weight: 0.58 kg (1.28 lbs)

• Gross Weight: 0.72 kg (1.59 lbs)

• Dimensions: 177.8 mm x 35.6 mm x 298.5 mm

• Interface Protocol: Bailey Plant Loop / Module Bus

• Power Requirements: +5 VDC supplied via backplane

Features

• Network Bridging: Provides a seamless link between localized module buses and the facility-wide plant loop for integrated site control.

• Deterministic Throughput: Optimized for real-time data transmission, ensuring that critical control signals reach their destination within strict timing windows.

• Data Buffer Management: Features onboard memory to manage asynchronous data traffic and prevent packet loss during high-load network conditions.

• Signal Isolation: Built-in electrical protection safeguards the internal processing logic from external network noise and ground loops.

• Hardware Diagnostics: Integrated front-panel status indicators provide immediate visual feedback regarding network activity and module hardware integrity.
