Product Details
The ABB INLIM03 INBIM02, also cataloged as the INLIM03 Bridge Controllers, operates as a dedicated hardware component for high-speed module bus communication and system interface routing within ABB Bailey INFI 90 Harmony platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | INLIM03 |
| Part Number | INLIM03 & INBIM02 |
| Brand | ABB |
| Product Type | Bridge Controllers |
| Origin | USA |
| Weight | 0.85 kg |
| Dimensions | Standard INFI 90 module rack width |
| Operating Temp | 0 to +55 deg C |
| Power Consumption | 24 VDC (Backplane bus supplied) |
| System Platform | INFI 90 / Network 90 / Harmony |
| Interface Type | Local Loop Interface / Module Bus Bridge |
Backplane Bus Communication Velocity and Deterministic Control
The bridge controller manages high-throughput packet transfers across internal node buses, maintaining backplane bus communication velocity and network synchronization between processing units. Integrated firmware flash compatibility supports deterministic instruction handling and protocol translation across INFI 90 and Harmony loop topologies. Embedded bus isolation circuits shield data lines against high-frequency electrical noise and field power line transients.
Frequently Asked Questions
Q: What function does the INLIM03 module perform in an INFI 90 rack assembly?
A: The INLIM03 acts as a local loop interface module to route control signals and data packets between local node buses and central processing units.
Q: Can the INLIM03 bridge module be hot-swapped while the rack power is active?
A: No, module power must be de-energized before extracting or inserting the unit to prevent electrical damage to backplane bus pins.
Q: How is chassis earth grounding established for the INLIM03 unit?
A: Grounding is secured mechanically through the front plate faceplate retaining screws when tightly mounted to the module rack frame.
Field Installation Guidelines
- Turn off all primary power sources supplying the INFI 90 module rack prior to inserting or removing the INLIM03 unit.
- Wear a grounded electrostatic discharge (ESD) wrist strap prior to handling the circuit board assembly.
- Slide the module evenly into its designated rack slot until the rear edge connector seats fully into the backplane socket.
- Fasten the top and bottom front panel screws to ensure mechanical locking and establish frame grounding continuity.
- Keep signal cables separated from high-voltage AC conductors by a minimum physical clearance of 200 mm to suppress noise coupling.
