Product Overview
The Triconex 8306A serves as the high-integrity power foundation for Triconex control systems. This AC-to-DC power module converts universal line voltage (100–240 VAC) into a stable, regulated 24V DC output to drive internal logic and field-side components. It features a ruggedized design capable of sustaining continuous 120W output in extreme thermal environments. We supply this product as 100% Brand New and Original factory-sealed stock.
Technical Specifications
| Parameter | Specification |
| Input Voltage | 100–240 VAC (50/60 Hz) |
| Output Voltage | 24 VDC |
| Output Current | 5 Amps |
| Power Rating | 120 Watts |
| Operating Temperature | -40°C to +70°C |
| Vibration Resistance | 0.5g RMS (5 Hz to 500 Hz) |
| Shock Resistance | 15g, 20 msec half-sine |
| Reliability (MTBF) | > 250,000 Hours |
| Maintainability (MTTR) | < 2 Hours |
Engineering Advantages
-
Thermal Resilience for Remote Deployment: The 8306A operates efficiently across a broad temperature range of -40°C to +70°C. This wide thermal envelope allows for installation in non-climate-controlled cabinets or remote field enclosures without the risk of thermal derating.
-
High-Availability Design: With a Mean Time Between Failures (MTBF) exceeding 250,000 hours, this module minimizes unscheduled downtime. In the event of a fault, the Mean Time To Repair (MTTR) stays under 2 hours, ensuring rapid restoration of safety-critical functions.
-
Superior Shock and Vibration Damping: The internal circuitry withstands 15g shocks and continuous 0.5g RMS vibration. These specifications protect the power rail from the mechanical stresses found in oil and gas pumping stations or heavy mining operations.
-
Universal Utility: The wide-range 100-240 VAC input accommodates global power standards, simplifying procurement for international projects and reducing the need for region-specific transformers or stabilizers.
FAQs
-
Can the 8306A handle momentary voltage surges from the main power grid?
Yes. The module includes internal filtering to mitigate common industrial power transients. However, we recommend external surge protection for sites with frequent lightning strikes or severe grid instability to maximize the 250,000-hour MTBF.
-
Does the module require active cooling fans?
The 8306A utilizes high-efficiency conversion to minimize heat dissipation. In most standard installations within the specified temperature range, passive convection cooling suffices, provided you maintain the recommended spacing within the Tricon chassis.
-
Is the 8306A compatible with older Tricon chassis versions?
The 8306A follows the standard Triconex form factor. Always verify your specific backplane and chassis model number to ensure the current draw of your total I/O load does not exceed the 5-amp capacity of a single module.
