Product Details
The ABB 1MRK002266-AAr02, also cataloged as the 1MRK002266-AA Optical Ethernet Module, operates as a dedicated hardware component for fiber-optic network interfacing within ABB industrial protection and control platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 1MRK002266-AAr02 |
| Brand | ABB |
| Origin | Standard ABB Manufacturing |
| Weight | 1.52 kg |
| Dimensions | 74 mm x 370 mm x 361 mm |
| Operating Temp | -25 to +70 deg C (Standard Industrial Range) |
| Power Consumption | Backplane Auxiliary Supply Powered |
| Optical Interfaces | 2 Glass Fiber Interfaces for Ethernet |
| Transmission Type | Long-Distance Optical Ethernet |
| Product Type | Optical Ethernet Module |
Backplane Bus Communication Velocity & Deterministic Networks
The optical Ethernet module routes network traffic via 2 glass fiber interfaces to facilitate long-distance data transmission without susceptibility to electromagnetic interference. High-speed backplane bus communication velocity allows seamless internal packet exchange between the optical interface controller and main system CPUs. Maintaining deterministic networks across fiber links prevents packet jitter, while unified firmware flash compatibility ensures synchronized communication parameters across chassis revisions.
Frequently Asked Questions
Q: What optical connector interface configuration is provided on the 1MRK002266-AAr02 board?
A: The module features 2 onboard glass fiber optical interfaces dedicated to industrial Ethernet network connections.
Q: How does fiber-optic transmission benefit signal path integrity in substation environments?
A: Glass fiber optics eliminate ground loop currents and provide full galvanic immunity against high-voltage electrical noise and EMI transients along long cable runs.
Field Installation Guidelines
- Always power down the host chassis subrack before inserting or removing the module from its card slot.
- Keep protective dust caps installed on optical transceivers until glass fiber patch cables are ready for final termination.
- Maintain minimum fiber optic cable bend radii during routing to prevent attenuation loss and signal degradation.
- Torques module faceplate retaining screws properly to guarantee low-impedance ground bonding with the chassis rack.
