140CPS11100 | Schneider Electric Modicon Quantum Standalone Power Supply Module

Product Overview

The Schneider Electric 140CPS11100 serves as a high-performance standalone power supply module for the Modicon Quantum automation platform. It converts AC input voltage into a stabilized 5.1V DC output to energize modules residing on the Quantum backplane. This unit provides a steady 3A current, supporting medium-to-large I/O configurations with high conversion efficiency. We offer this module as 100% brand new, original equipment in factory-sealed packaging, ensuring maximum system uptime for your critical control infrastructure.

Technical Specifications

The 140CPS11100 accommodates a wide range of AC input voltages and provides comprehensive internal protection for the backplane electronics.

Engineering Advantages

• Wide Range Voltage Compatibility: This module accepts a broad input spectrum from 100V to 276V AC. This flexibility allows the Quantum system to operate reliably across global power grids and handles significant line voltage fluctuations without interrupting the PLC logic.

• Integrated Overload Protection: Built-in internal overvoltage and overload protection circuits shield the expensive processor and I/O modules from power surges or field-side faults. This eliminates the risk of cascading hardware failure during electrical anomalies.

• Low Harmonic Distortion: The 140CPS11100 limits harmonic distortion to less than 10% of the fundamental RMS value. This clean power output prevents electromagnetic interference with sensitive analog I/O modules, ensuring high signal integrity throughout the rack.

• Rapid Diagnostic Feedback: A prominent green "PWR OK" LED provides immediate visual confirmation of the power status. Engineers can verify the health of the DC bus at a glance, significantly speeding up onsite troubleshooting during commissioning or maintenance.

• Hazardous Location Certification: With FM Class 1 Division 2 certification and UL 508 compliance, this power supply operates safely in volatile industrial environments, such as oil and gas or chemical processing facilities.

FAQs

• Can I use the 140CPS11100 in a redundant power configuration?

  No. This specific model functions as a standalone power supply. If your application requires redundant power (summing two supplies), you should select a Quantum module specifically designed for redundancy, such as the 140CPS114x0 series.

• What type of fuse should I use for external protection?

  Schneider recommends an associated 1.5 A slow-blow fuse. This protects the module from high inrush currents during startup while maintaining a safety buffer for continuous operation.

• Does the 140CPS11100 support high-altitude installations?

  Yes. This module maintains its rated performance at operating altitudes up to 16,404.2 feet (5000 m), making it suitable for specialized mining or aerospace testing facilities.

• Is this a refurbished or surplus unit?

  Absolutely not. We guarantee this 140CPS11100 is 100% Brand New original Schneider Electric stock. It arrives in the original factory package with the GTIN 3595861135208 intact.
