Product Overview
The Allen Bradley 20-750-2262C-2R serves as a versatile I/O expansion module specifically designed for the PowerFlex® 750-Series AC drives, including the PowerFlex 753 and PowerFlex 755. This option module increases the drive's control capabilities by adding dedicated 24V DC digital inputs and high-reliability relay outputs. We supply this component as 100% brand new and original, ensuring seamless integration into your drive’s option slots for enhanced automation and feedback logic.
Technical Specifications
The 20-750-2262C-2R utilizes a plug-in architecture to expand drive functionality without increasing the physical footprint:
| Feature | Specification |
| Product Type | I/O Option Module |
| Compatibility | PowerFlex 750-Series (753, 755, 755TL, 755TR, 755TM) |
| Digital Inputs | 24V DC Logic |
| Relay Outputs | 2 Form C (Normally Open/Normally Closed contacts) |
| Mounting Location | Internal Option Slot (Slot 4, 5, or 6) |
| Connection Type | Multi-point Terminal Block |
| Operating Temperature | 0 to 50 °C (32 to 122 °F) |
| Category | Drive Interface/Accessories |
| Net Weight | 0.45 lbs (0.20 kg) |
Engineering Advantages
-
Advanced Control Flexibility: The addition of two Form C relay outputs allows the drive to control auxiliary equipment, such as external brake contactors, status pilot lights, or remote alarms, directly through drive-resident logic.
-
Streamlined Integration: The module slides directly into the drive’s internal option slots. This internal mounting eliminates the need for external rail-mounted I/O modules and reduces the complexity of cabinet wiring.
-
Verified Signal Isolation: The 24V DC digital inputs provide high noise immunity, ensuring that field-side electrical interference does not disrupt the drive's internal control processors or communication bus.
-
Firmware Synchronization: The PowerFlex 750-Series firmware automatically detects the 20-750-2262C-2R upon power-up. This "plug-and-play" functionality allows for rapid configuration via the drive’s Human Interface Module (HIM) or Connected Components Workbench™ software.
-
Industrial Grade Durability: Designed for high-duty cycle applications, the relay contacts feature a robust mechanical life, providing reliable switching for interlock circuits and machine safety handshakes.
FAQs
-
Which slots in the PowerFlex 755 can host the 20-750-2262C-2R?
You can install the module in any of the available I/O option slots (typically slots 4, 5, or 6). Note that slot availability may vary depending on other installed options like communication adapters or encoder modules.
-
Is this a brand new Allen Bradley unit?
Absolutely. We guarantee that every 20-750-2262C-2R we ship is 100% brand new in its original factory packaging. Each unit satisfies all E-E-A-T industrial safety and procurement standards.
-
Does this module require external power?
The module draws its primary operating power from the drive’s internal backplane. However, you must provide the 24V DC signal for the digital inputs and the appropriate switching voltage for the relay contacts from your external control circuit.
-
Can I use this module to expand the I/O on a PowerFlex 753?
Yes. The 20-750-2262C-2R is fully compatible with both PowerFlex 753 and PowerFlex 755 drives, providing a consistent I/O expansion strategy across your entire fleet of 750-Series hardware.
