Product Description
The Allen Bradley Compact I/O 1769-IQ6XOW4 is a combination module that integrates six 24V DC input points with four relay output points in a single unit. Designed for use with CompactLogix and MicroLogix 1500 systems, it provides flexible signal handling, high isolation voltage, and efficient installation features.
Technical Specifications
-
Manufacturer: Allen Bradley
-
Product Line: Compact I/O
-
Catalog Number / Model: 1769-IQ6XOW4
-
Product Type: Digital Combination Module
-
Compatibility: CompactLogix and MicroLogix 1500 systems
-
Inputs: 6 digital inputs, 24V DC
-
Outputs: 4 relay outputs
-
Output Voltage Range: 5–265V AC or 5–125V DC
-
Current per Output: 2.5A at 30V DC or 2.5A at 120V AC
-
Isolation Voltage: 1500V AC (input to output)
-
Power Consumption: 2.5 W
-
Dimensions: 118 × 87 × 35 mm
-
Weight: 0.3 kg
-
Mounting: DIN rail installation
-
Features: LED indicators for each channel, removable terminal blocks for simplified wiring
Application Scenarios
-
Compact control panels requiring both input and output functionality in one module
-
Machine automation systems with limited space but high reliability needs
-
Applications requiring flexible AC/DC relay outputs alongside DC inputs
FAQ
Q: How many input and output points does the 1769-IQ6XOW4 provide? A: Six DC inputs and four relay outputs.
Q: What isolation voltage is supported? A: 1500V AC between input and output.
Q: Is the module suitable for CompactLogix systems? A: Yes, it is compatible with CompactLogix and MicroLogix 1500.
Comparison with Similar Models
-
1769-IQ6XOW4: 6 DC inputs, 4 relay outputs.
-
1769-IA16: 16 AC input module.
-
1769-OB16: 16 DC output module.
