GE Bently Nevada 3500/15 127610-01 Power Supply Module

GE Bently Nevada 3500/15 127610-01 Power Supply Module

New Bently Nevada 3500/15 127610-01 Power Supply Module

  • Brand:

    Bently Nevada
  • Item No.:

    Bently Nevada 3500/15 127610-01
  • Payment:

    TT,Western Union
  • Product origin:

    USA
  • Goods_stock:

    20
  • Shipping port:

    Xiamen
  • Lead Time:

    1-3 days
  • Condition:

    Original New
  • Warranty:

    1 Year
  • Certificate:

    Co,Coo
  • Product Type:

    Bently Nevada 3500 Power Supply
  • System:

    3500 Monitor System

GE Bently Nevada 3500/15 127610-01 Power Supply Module for 3500 system


Introduction

The 3500/15 AC and DC Power Supplies are half-height modules and must be installed in designated slots on the left side of the rack. The 3500 rack can contain one or two power supplies with any combinations of AC and DC. Either supply can power a full rack. When two power supplies are installed in a rack, the one in the lower slot acts as the primary supply, and the other in the upper slot acts as the backup supply. If installed, the second supply is the backup for the primary one.


The 3500/15 AC and DC Power Supplies accepts a wide range of input voltages and converts them to voltages acceptable for use by other 3500 modules. The following power supplies are available with the 3500 Series Machinery Protection System

Universal AC Power l High Voltage DC Power Supply l Low Voltage DC Power Supply


Specifications

Part No. 3500/15
Order No. 127610-01
Power Supply Module  Dimensions
(Height x width x depth)
120.7 mm x 50.8 mm x 251.5 mm
4.75 in x 2.0 in x 9.9 in
Weight 1.39 kg, 3.06 lb
Input Voltage 110 to 220 Vac nominal, 85 to 264 Vac rms, 120 to 373 Vac pk
