Honeywell 8C-PDIDA1 Digital Output Module | PLC Control Module

Overview

The 8C-PDIDA1 is a high-performance digital output module within Honeywell's Series 8 PLC platform. It delivers reliable and precise signal control for discrete output devices in process control and automation systems.

Key Features

• Provides 32 isolated digital output channels

• Supports standard 24 V DC outputs with configurable load

• Fast response time suitable for real-time control

• Full electrical isolation for enhanced signal integrity

• DIN rail mountable with compact footprint

Technical Specifications

• Model: 8C-PDIDA1

• Output Channels: 32 digital outputs

• Nominal Voltage: 24 V DC

• Output Voltage Range: 0–30 V DC

• Maximum Load Current per Channel: 100 mA

• On-State Voltage: 24 V DC (typical)

• Off-State Voltage: 0 V DC

• Leakage Current: ≤5 µA in off-state

• Response Time: ≤10 ms

• Module Power Consumption: 1.5 W (nominal)

• Mounting: DIN rail

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Humidity: 5%–95% non-condensing

Applications

Ideal for process control systems requiring accurate digital signal outputs, including PLC-controlled machinery, automated production lines, and Experion PKS or TPS integration.

FAQ

Q: Can the 8C-PDIDA1 module handle high-frequency switching?
A: Yes, the module supports rapid response times up to 10 ms, suitable for real-time process control.

Q: Is the module compatible with redundant PLC setups?
A: It integrates seamlessly with Series 8 PLC architectures, including fault-tolerant systems when paired with compatible I/O assemblies.

Q: How is the module mounted?
A: The module is DIN rail mountable for secure installation in standard control cabinets.
