Product Details
Configured for analog signal processing within Mark V turbine control systems, the GE DS200TCCBG1B (DS200TCCB Analog I/O Board) provides direct physical execution of signal conversion and interface management.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200TCCBG1B |
| Brand | GE |
| Core Performance | 80196 CPU, PROM modules, 50-pin I/O connectivity |
PLC/DCS Industrial Control Integration
The DS200TCCBG1B integrates into the Mark V control architecture to perform analog data acquisition and signal distribution. The module utilizes an onboard 80196 CPU to manage data processing, relying on specific firmware flash compatibility to maintain synchronization with the turbine control system bus. I/O density scaling is achieved through high-density 50-pin connectors (JCC, JDD), while deterministic network performance is governed by the system's backplane bus communication velocity. Hardware settings are adjusted via physical jumpers (JP1-JP3) to align the board's electrical response with the specific requirements of the connected drive or sensor loops.
Frequently Asked Questions
Q: Are the jumpers on this board software-configurable?
A: No. The DS200TCCBG1B uses physical jumpers to configure hardware settings. Configuration changes must be performed manually by repositioning the jumpers on the designated pins.
Q: Can this module be hot-swapped while the system is powered?
A: No. The module must be de-energized before installation or removal. Hot-swapping can induce voltage spikes that may damage the onboard 80196 CPU or the PROM memory modules.
Q: What is the function of the JTEST and TCQPL connectors?
A: These connectors are reserved for manufacturer-level diagnostics and factory testing. They are typically not utilized during standard field operation or site-level configuration.
Field Installation Guidelines
- Jumper Configuration: When adjusting jumpers JP1, JP2, or JP3, ensure the shunt is firmly seated across the intended pin pair. Do not use excessive force, as the jumper pins are susceptible to mechanical bending.
- Connector Integrity: Inspect the 50-pin connectors (JCC and JDD) for bent pins or oxidation before mating. Ensure cables are fully latched to prevent intermittent signal loss during high-vibration operation.
- Static Management: The board contains sensitive PROM and microprocessor components. Use a grounded wrist strap at all times when handling or configuring the module to prevent electrostatic discharge (ESD) damage.
- Documentation Adherence: If the module replacement requires changes from default jumper positions, strictly follow the specific technical documentation provided with the hardware to ensure correct loop response.
