Product Details
Overview
The Allen-Bradley 1786-TPR is a rugged industrial-grade cable connector designed for use in ControlNet communication networks. It provides a secure and reliable connection between trunk and tap cables, maintaining signal integrity and minimizing installation space requirements. Its right-angle design supports flexible routing within confined control enclosures and industrial environments.
Technical Specifications
-
Manufacturer: Allen-Bradley
-
Model Number: 1786-TPR
-
Product Type: Right-Angle Cable Connector
-
Connection Type: BNC-style coaxial connector for ControlNet trunk cables
-
Orientation: 90° right-angle configuration
-
Impedance: 75 Ω nominal
-
Maximum Transmission Distance: Up to 1,000 m (using RG-6 coaxial cable)
-
Cable Compatibility: ControlNet RG-6/U quad-shielded coaxial cable
-
Shielding: Full metal body for electromagnetic interference (EMI) protection
-
Operating Voltage: 24 V DC (nominal system voltage support)
-
Operating Temperature Range: 0 °C to +60 °C (32 °F to 140 °F)
-
Storage Temperature Range: −40 °C to +85 °C (−40 °F to 185 °F)
-
Protection Rating: IP20 (for use within protective enclosures)
-
Material: Nickel-plated brass housing with gold-plated center contact
-
Mounting Method: Inline coupling between trunk and drop cables
-
Weight: Approx. 40 g
Key Features
-
Reliable Network Performance: Ensures consistent ControlNet signal transmission with low insertion loss.
-
Compact 90° Design: Reduces cable bend radius for better routing in tight installation areas.
-
Durable Construction: Metal housing and gold-plated contact provide mechanical strength and corrosion resistance.
-
Quick Installation: Simple BNC connection allows secure attachment without specialized tools.
-
Noise Immunity: Full shielding prevents interference in high-EMI industrial environments.
Application Scenarios
-
ControlNet network installations in manufacturing and process automation
-
Compact control cabinets requiring right-angle cable orientation
-
Distributed control systems (DCS) and PLC communication setups
-
Industrial robotics, drives, and motion control systems using coaxial data networks
FAQ
Q1: What type of network is the 1786-TPR connector designed for?
It is specifically engineered for Allen-Bradley ControlNet coaxial communication systems.
Q2: Can it be used with other 1786 series connectors?
Yes. The 1786-TPR is compatible with other ControlNet connectors such as 1786-TPS and 1786-TPYR.
Q3: Does it support field installation?
Yes. The connector is field-installable and designed for quick assembly with standard ControlNet coaxial cables.
