Product Details
The General Electric DS200SDCIG1A, also cataloged as the DS200SDCIG1 DC Power Supply and Instrumentation Board, operates as a dedicated hardware component for power regulation and signal instrumentation within Mark V turbine control and DC2000 drive platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | DS200SDCIG1A |
| Brand | General Electric |
| Origin | USA |
| Dimensions | Standard Mark V PCB form factor |
| Operating Temp | Per standard industrial control specifications |
| Function | Instrumentation of armature/field current and voltage |
Industrial Control and Firmware Compatibility
The DS200SDCIG1A module interfaces with Mark V rack backplanes and DC2000 drive assemblies. It facilitates accurate monitoring of AC line and DC motor signals, including voltage magnitude and phase sequence parameters. The board architecture requires precise backplane bus communication velocity settings to ensure data synchronization with the primary controller. Firmware flash compatibility must be validated against the Mark V system processor revision to support the instrumentation logic inherent in the SDCI board. The design allows for I/O density scaling when integrating multiple boards within the drive control loop.
Frequently Asked Questions
Q: Does the board support on-line hot-swapping?
A: No. All electrical current must be removed from the drive cabinet and sufficient discharge time allowed before board removal. Hot-swapping is restricted due to potential high-voltage exposure.
Q: How is signal instrumentation handled on the board?
A: The board features integrated circuits designed to instrument armature and field current and voltage signals. Status is monitored via individual LED indicators mapped to the fuse components for immediate fault diagnostics.
Field Installation Guidelines
- Safety Compliance: Ensure total isolation of the DC drive power supply before cabinet entry. Verify the absence of voltage using a calibrated multimeter.
- Component Handling: When removing or installing, minimize contact with plastic snaps, panels, and adjacent PCBs to prevent physical damage.
- Cable Disconnection: When separating ribbon cables, apply pressure to both connector bodies simultaneously. Do not pull directly on the ribbon cable to avoid pin misalignment or conductor fracture.
- Wiring Inspection: In the event of a blown fuse (indicated by LED), inspect the local wiring for short circuits or insulation degradation prior to replacing the fuse or the board.
- Grounding: Maintain secure mounting to the chassis using all available hardware to ensure the PCB maintains a common reference potential for instrumentation accuracy.
