Product Details
The GE FC200656-03, also cataloged as the FC200656 PC2IPIIB BEP Board, operates as a dedicated hardware component for high-speed signal routing and system interface processing within GE VIVID 7 ultrasound systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FC200656-03 |
| Brand | GE (GE Vingmed Ultrasound) |
| Origin | USA |
| Operating Temp | Standard industrial operating range |
| Power Consumption | Standard backplane power input |
| Component Type | PC2IPIIB Back-End Processor (BEP) Card |
| System Platform | GE LOGIC 9 / VIVID 7 Systems |
| Subsystem | Vingmed Ultrasound BEP Architecture |
Backplane Bus Communication Velocity & Deterministic Network Execution
The FC200656-03 PC2IPIIB card processes image acquisition data and control signals across backplane bus communication velocity pathways within the Back-End Processor (BEP) card cage. Internal data transfer lines ensure low-latency packet routing between the primary computing unit and front-end signal channels.
Designed to meet strict firmware flash compatibility parameters across VIVID 7 revision builds, the card maintains deterministic data transfer across EtherNet/IP deterministic networks. The hardware architecture supports system-level I/O density scaling to handle high-bandwidth real-time sensor array calculations without system clock drift or processing bottlenecks.
Frequently Asked Questions
Q: What primary subsystem within the GE VIVID 7 platform utilizes the FC200656-03 board?
A: The FC200656-03 functions specifically inside the Back-End Processor (BEP) assembly as the PC2IPIIB interface card.
Q: Is live insertion or extraction supported for the FC200656-03 card during active equipment operation?
A: No. System power to the main enclosure must be completely disconnected and isolated prior to pulling or installing the card to prevent bus logic damage.
Q: What precautions should be taken regarding electrostatic discharge (ESD) during board handling?
A: Technicians must wear a grounded anti-static wrist strap connected to a bare metal chassis ground point to avoid electrostatic damage to onboard integrated circuits.
Field Installation Guidelines
- Power Shutdown: Turn off the main system circuit breaker and disconnect primary AC power from the equipment frame before opening the card cage.
- Anti-Static Discharge: Connect a grounded ESD wrist band to an unpainted metal frame point before removing the card from its anti-static shielding packaging.
- Card Slot Insertion: Slide the FC200656-03 card evenly along the chassis slot card guide rails until the backplane connectors align with the rear socket.
- Connector Engagement: Press the card firmly into the rack backplane to seat all connector pins, then tighten all front panel thumbscrews.
- Final Inspection: Verify that all adjacent card interfaces and retaining hardware are secured before restoring power to the system enclosure.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
