Product Details
Product Overview
The DS200LDCCH1AKA functions as the primary Drive Control and LAN Communications Board (LDCC) within the GE Mark V Speedtronic ecosystem. This high-performance module executes core control algorithms and manages high-speed data exchange between the turbine control core and peripheral I/O boards. By utilizing the Intel 80196 microcontroller, this board synchronizes complex drive operations with nanosecond precision. We supply this unit as 100% Brand New, ensuring your system operates with peak original manufacturer performance and factory-certified stability.
Technical Specifications
The DS200LDCCH1AKA integrates a robust electrical architecture to handle mission-critical industrial automation tasks:
| Specification | Technical Detail |
| Manufacturer | General Electric (GE) |
| Series | Mark V Speedtronic DS200 |
| Microprocessor | Intel 80196 Microcontroller |
| Onboard Memory | Integrated EPROM + RAM (Firmware & Data) |
| Communication | LAN Interface + Dedicated Serial Diagnostic Ports |
| PCB Coating | Conformal Coating (Moisture/Dust Resistance) |
| Functional Revisions | Revision A (1st), Revision K (2nd) |
| Artwork Revision | Revision A |
| Weight | 0.45 kg |
| Hardware Protection | Integrated Onboard Fuses & LED Fault Indicators |
Engineering Advantages
-
Optimized Computational Power: The Intel 80196 microcontroller processes real-time data from turbine sensors and executes drive regulation commands without perceptible latency, maintaining tight control loops.
-
Consolidated Communication Architecture: This board integrates drive control and LAN communications into a single PCB. This consolidated design reduces the physical footprint in the control cabinet and simplifies the communication bus between the controller and I/O modules.
-
Industrial-Grade Conformal Coating: The specialized conformal coating protects delicate surface-mount components from humidity, salt air, and airborne contaminants typical of power generation environments.
-
Direct Diagnostic Access: Onboard serial ports allow engineers to connect a laptop directly to the LDCC board for real-time monitoring. The LED fault indicators provide immediate visual feedback, accelerating the troubleshooting process.
-
Firmware Reliability: The integrated EPROM chips store critical system firmware securely, preventing data corruption during power cycles or emergency shutdowns.
Installation & System Protocol
-
Electrostatic Discharge (ESD) Safety: Always wear a grounded wrist strap when handling the DS200LDCCH1AKA. The high-density Intel microcontroller remains highly sensitive to static discharge.
-
Firmware Verification: Ensure the EPROM chips on the new board match your specific turbine requirements. You may need to transfer existing chips if your system utilizes site-specific custom control logic.
-
Connector Alignment: Exercise extreme caution when mating the board with the turbine backplane. The high-density pin connectors require precise alignment to prevent bent pins and intermittent communication failures.
-
Fuse Check: Verify that all onboard fuses remain intact before powering up the drive to prevent initialization errors during the "Power-On Self-Test" (POST).
FAQs
Q: What is the primary function of the Intel 80196 processor on this board?
A: The Intel 80196 acts as the central logic processor. It interprets signals from turbine sensors, manages the LAN communication traffic, and executes the control loops necessary to regulate turbine speed and torque.
Q: Can the DS200LDCCH1AKA replace an older LDCC board with different revision levels?
A: Yes. This "AKA" revision typically maintains backward compatibility within the Mark V series. However, you must verify your drive's firmware version via the serial port to ensure the software supports the specific hardware features included in Revision K.
Q: How does the conformal coating improve board longevity?
A: The conformal coating provides a non-conductive protective layer that insulates the circuitry from environmental stressors like dust, moisture, and chemical vapors, effectively preventing corrosion and electrical shorts in turbine control cabinets.
Q: Does the board arrive with pre-installed RAM and EPROM?
A: This 100% Brand New unit includes factory-standard RAM and EPROM chips. For specialized turbine applications, engineers often swap the EPROM chips to match the unique control parameters and custom logic of the specific installation site.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
