Product Details
Description
The ABB NTAI04 is a dedicated 16-channel RTD interface for Infi 90 and Network 90 systems. It provides physical termination for field temperature sensors, utilizing 3-wire lead-wire compensation to ensure measurement precision over long distances.
Specifications
-
Brand: ABB Bailey
-
Model Number: NTAI04
-
Product Type: RTD Analog Input Termination Unit
-
Series: Infi 90 / Network 90
-
Input Channels: 16 independent RTD inputs
-
Sensor Compatibility: Supports 100-ohm Platinum (Pt) RTDs and other standard types
-
Wiring Configuration: Designed for 3-wire RTD lead-wire compensation
-
Interconnect: Connects to IMASI modules via NKTU ribbon cables
-
Mounting: Standard NMOI series mounting base compatible
-
Product Net Weight: 0.46 kg (1.01 lbs)
-
Dimensions: 177.8 mm x 35.6 mm x 127 mm
Features
-
Precise Thermal Interfacing: Specifically calibrated to handle the low-voltage millivolt signals generated by RTDs without introducing measurement bias.
-
Lead-Wire Compensation: Supports 3-wire circuitry to automatically nullify the resistance effects of field wiring, ensuring the DCS receives only the actual sensor resistance.
-
High-Density Monitoring: Provides termination for up to 16 sensors on a single board, maximizing the I/O capacity of the control cabinet.
-
Rugged Connection Points: Features industrial-grade screw terminals designed to maintain high-pressure contact, preventing signal fluctuation caused by vibration or oxidation.
-
Passive Signal Protection: Operates as a robust passive interface with integrated filtering to shield sensitive analog-to-digital converters from field-induced electrical noise.
Additional Information
- 100% Genuine Parts: All products are original and authentic, ensuring reliable industrial performance.
- 30-Day Refund Guarantee: Return any in-stock item within 30 days in original, unopened packaging for a full refund (excluding shipping and fees).
- 12-Month Warranty: Covers defects in materials or workmanship; excludes misuse, normal wear, or unauthorized modifications.
- Worldwide Shipping: We ship via USPS, UPS, FedEx, and DHL. Delivery times vary by country and may be subject to customs or import fees.
- Support & Contact: Technical and warranty assistance is available anytime. Contact us here: Contact.
- Purchase Guidance: Check product specifications and compatibility carefully before ordering to ensure proper application.
