Bachmann DIO216 DIO216/x Electric PLC Digital Input/Output Modules
Item No.:
Bachmann DIO216Payment:
TT or Western UnionProduct origin:
GermanyShipping port:
XiamenLead Time:
1-3 working daysCondition:
Original NewWarranty:
1 YearCertificate:
Co,CooProduct Type:
Digital Input/Output ModuleSystem:
Bachmann ElectronicOriginal New Bachmann DIO216 Electric PLC Digital Input/Output Modules in Stock
Introduction
DIO216/x, DIO232 Digital Input/Output Modules The digital input / output modules DIO216/x and DIO232 can be used to operate receivers of digital control devices such as contactors, relays, pneumatic and hydraulic valves as well as for reading signals from digitally operating sources such as sensors, photocells or switches.
1.16 / 32 digital channels
2.16 channels can be configured as input or output
3.Configurable interrupt inputs
4.Status display for each channel via LED
5.Supply voltage 18 to 34 VDC
6.Supply voltage protected against reverse polarity
7.Cost effective and space saving
8.Full wiring without extra potential rails (3-wire, only DIO216)
9.Configurable input filter (DIO232)
Technical Data
| Bachmann PLC I/O Module | DIO216 |
DIO216/4 DIO216/4 CC |
DIO232 DIO232 CC |
| Inputs Quantity | Max. 16 | Max. 16 | 16 to 32 |
| Input voltage range (H) | 15 to 34 VDC | 15 to 34 VDC | 15 to 34 VDC |
| Input delay (normally) | 600 µs | 600 µs | 40 μs bis 365 ms,default 3 ms |
| Output current per channel (max.) | 1 A | 1 A | 0.5 A |
| Total current (max.) | 12 A | 16 A | 8 A |
| External power supply | Yes | Yes | Yes |
| Approvals / Certificates | CE, UL/cUL, CCC | CE, UL/cUL, CCC | CE, UL/cUL, CCC |
Order code for DIO216/x, DIO232 Series
DIO216 00010615-00 Digital input/output module; 16x DIO; 24V / 1A
DIO216/4 00010892-00 Digital input/output module; 16x DIO; 24V / 1A
DIO216/4 CC 00016141-00 Like DIO216/4
DIO232 00013034-00 Digital input/output module; 16x DI
DIO232 CC 00019502-00 Like DIO232
